Die Kontrolleinheit dient zur manuellen Bedienung des Motorfokussierers über die Tastenfelder ebenso wie zum Anschluss an den PC. Sie enthält die Steue- rungselektronik. 1. Steeldrive II (SD II) Controller Gehäuse 2. Micro-USB Kabel (3 m) 3. 12V / 5A Netzteil mit EU-Stecker 4.
4. Steeldrive II: Mögliche Betriebsarten Motor Sensor 12V DC 1. Manuell: Der Steeldrive II wird manuell über die Handsteuerbox betrieben. Lernen Sie dazu Beschriftung der vier Knöpfe und zwei LEDs auf der Vorderseite des SD II Controllers nachfolgend die einzelnen Tasten und deren Funktionen kennen.
Sekunden lang gedrückt bis LED 2 erlischt. 1. Drücken Sie SET , um in den Einstellungsmodus zu wechseln (LED 2 Der äußere Grenzwert ist nun gespeichert, und der Steeldrive II Controller leuchtet) wechselt wieder in den Normal-Modus (alle LEDs sind aus).
Seite 8
High precision, temperature compensating focusing motor for heavy loads MADE IN GERMANY Baader Steeldrive II Controller # 2957260 – EN ver. 03/2019 – BAADER PLANETARIUM Zur Sternwarte 4 • D-82291 Mammendorf • Tel. +49 (0) 8145 / 8089-0 • Fax +49 (0) 8145 / 8089-105...
See image below. pad as well as to connect it to a computer. The control electronics are built into this unit. 1. Steeldrive II (SD II) Controller 2. Micro-USB Cable (3 m) 3. 12V / 5A power supply with EU-plug 45 mm 4.
RJ45-cable can keep the strain away from the other cables. ° 4. Steeldrive II: Three Operation Modes 1. Manual: The Steeldrive II focuser is operated Motor Sensor 12V DC completely with the keys on the controller. To...
2. Push and hold JOG for three seconds until LED 2 is off. Now, the current Now, the new value for the outer limit is saved, and the Steeldrive II returns to position is saved as favorite. the normal mode (all LEDs are off).
If you are in normal mode (LED 1 and 2 are off): If necessary, you can ignore the limits which are set in the Steeldrive II. This is e.g. useful if you want to set a new outer limit, which is farther outwards than 1.
