gB usEr ManuaL
LED continuous Light – DLP-2000 LED
thank you for purchasing our DÖrr DLP-2000 LED continuous Light. Please read this manual
carefully before using the light.
fEaturEs
For brilliant pictures and videos light of sufficient intensity is essential. Further the adjustment
of colour temperature is of great advantage, in order to avoid mixed light. The DÖRR LED
DLP-2000 continuous light combines the two essential features: It provides a maximum light
intensity of 12.000 Lux at 1m and is dimmable. The colour temperature of the long life LEDs can
be variably adjusted from 3000 K to 7000 K. For outdoor use, the DLP-2000 can be operated
with Sony V-mount batteries (optional). The light frame is fitted with a swivelling mount to fix
the DLP-2000 on a light stand. The colour neutral diffuser filter softens the light which is most
useful for portrait photography.
noMEncLaturE
1. Light panel
2. LED bulbs
3. Barndoors (detachable)
4. LCD screen
5. DC power jack
6. On/Off switch (0 = Off/1 = On)
7. White colour temperature dial control (cool light)
8. Yellow colour temperature dial control (warm light)
9. Battery mount for Sony V battery
10. Swivel mount
11. Battery lock

sPEcifications

Number of LEDs: 200
Light Intensity: max. 12.000 Lux (1m), dimmable
Power Output: 100 W
Colour Temperature: variably adjustable from 3.000 K - 7.000 K
Operating Voltage: DC-15V / 7A
LCD Display:
Dimensions: 460 x 240 x 80 mm
Dimensions illuminated area: 410 x 200 mm
Weight: 2660 g
Battery Socket: Sony V-mount (battery optional)
Content: LED Continuous Light, AC Adapter AC110-240V/DC15V/7A,
diffuser filter
WEEE inforMation
The Waste Electrical and Electronic Equipment Directive (WEEE Directive) is the European community directive on waste electrical and electronic equipment, which became
European law in February 2003. The main purpose of this directive is to prevent electronic waste. Recycling and other forms of waste recovery should be encouraged to reduce
waste. The symbol (trash can) on the product and on the packing means that used electrical and electronic products should not be disposed of with general household waste. It
is your responsibility to dispose of all your electronic or electrical waste at designated collection points. Disposing of this product correctly will help to save valuable resources
and it is a significant contribution to protect our environment as well as human health. For more information about the correct disposal of electrical and electronic equipment,
recycling and collection points please contact your local authorities, waste management companies, your retailer or the manufacturer of this device.
rohs conforMity
This product is compliant with the European directive 2011/65/EU of January 03, 2013 for the restriction of use of certain hazardous substances in electrical and electronic
equipment (RoHS) and its amendments.
cE MarKing
The CE marking complies with the European directives.
6
1
4
2
5
3
11
oPErating instructions
1. Insert the AC adapter into the DC power jack (5). Please ensure that On/Off switch (6) is
switched off = "0".
2. Adjust the requested colour temperature by turning the dial controls 7 and 8. Current value
will be shown on LCD screen (4).
(a) to create warmest light:
Turn the white colour dial control (7) to its left end (lowest level). Turn the yellow colour dial
control (8) to its right end (highest level). LCD screen shows: 3000 K.
(b) to create coolest light:
Turn the white colour dial control (7) to its right end (highest level). Turn the yellow colour
dial control (8) to its left end (lowest level). LCD screen shows: 7000 K.
(c) to create daylight temperature:
Turn both dial controls (7+8) to their right ends (highest level). The colour temperature
reaches 5000 K.
Optional: Battery installation (battery not included). Install the battery onto the battery mount
(9). For releasing the battery press the battery lock (11).

safEty hints

1. Turn off the continuous light after use.
2. Before plug or unplug the device always make sure that power is off=0.
3. Do not open or repair the device yourself (risk of electric shock). In case of defect please
contact specialized staff.
4. Provide adequate ventilation during operation. Protect the continuous light against rain and
humid environment.
5. For best light performance, clean the LEDs occasionally by wiping the surface gently with
7
8
a soft and dry cloth.
9 6. Only use specific Sony V Li-Ion batteries (optional).
7. Store the continuous light out of reach of children in a dry and dust-free place.
10
