Note:
• RX / TX mode can only be successfully switched after the
adapter is turned off for 3 seconds. After the switch, the
pairing history of the devices will be cleared.
• The SPDIF and AUX mode can be freely switched.
• In SPDIF mode, connect devices through SPDIF IN for TX mode
and SPDIF OUT for RX mode.

LED Indicators

LED Indicator
Solid Red LED
LED Off
Flashing Red and Blue
Flashing Red
Solid Blue LED
Status
Charging
Fully charged
Pairing in TX / RX mode
Low battery
Successfully paired
How to Use
Charging
1. Connect the Micro USB end of the charging cable to the
charging port of the Bluetooth adapter.
2. Plug the USB end of the charging cable to a USB charging
port or any active USB port.
3. The LED indicator will turn red when charging. It will
automatically turn off when the device is fully charged.
Note:
• You can use the adapter while it is charging.
• We recommend charging the unit for at least 2 hours before
using it for the rst time.
Pairing
Pair in TX mode:
1. Set the TT-BA09 to TX mode and connect it to your
non-Bluetooth audio transmitting device.
2. Place your Bluetooth audio receiving device, like earphones
or speakers, within a 3 feet / 1 meter range and set it to
pairing mode.
3. Turn on the TT-BA09 and tap the Power Button twice to enter
pairing mode. After approximately 10 seconds, pairing will be
complete.
