Cuppone Giotto Installationshandbuch Seite 49

Giotto
elementi interni - internal components
Parti di ricambio
Spare parts
Ersatzteile
Codice
Nr.
Code
31 91310050 Termostato sicurezza monofase
32 91310145 Contattore BF26.00
33 91610030 Vetro 220x93 GT 140
33 91610031 Vetro 192x93 GT 110
34 91310182 Portalampada 12V attacco G5.3
35 91310196 Lampada G4 12V 20W 300°
36 92610710 Fibraceramica per botola luce
37 91310211 Sonda TCJ per forni L.=1500mm
38 91310231 Morsettiera G10/5 Trifase
39 91310235 Morsettiera G5/12
40 91310257 Scheda di controllo 2T
41 91310270 Scheda di controllo cappa
42 91310305 Scheda di potenza 23A
42 91310306 Scheda di potenza (U.S.A.-CA)
43 91310310 Scheda inverter motore
44 91611155 Frontale comandi CP 2012
45 91310387 Pulsante D.22 Fungo rosso
46 91310391 Base fissaggio
47 91310403 Contatto NC rosso
48 91310404 Contatto NO verde
49 91310502 Fusibile 5x20F 1A
49 91310505 Fusibile 5x20F 10A
49 91310507 Fusibile 10x38 250V 1A UL (U.S.A.-CA)
49 91310508 Fusibile 10x38 250V 10A UL (U.S.A.-CA)
50 91310512 Portafusibile 5x20
51 91310515 Portafusibile 10x38 UL (U.S.A.-CA)
52 91310681 Joystick D.22
53 91310691 Selettore a 2 posizioni
54 91310750 Interruttore salvamotore
55 91310241 Morsettiera bam/6
56 91711155 Resistenza inferiore centrale 2700W GT140 Central lower heating element 2700W GT140
56 91711190 Resistenza inferiore centrale 2100W GT110 Central lower heating element 2100W GT110
56 91711170 Resist. inf. centrale 2950W UL GT140 (U.S.A.)
56 91711175 Resist. inf. centrale 2300W UL GT110 (U.S.A.)
57 91711156 Resistenza inferiore laterale 1350W GT140 Side lower heating element 1350W GT140
57 91711196 Resistenza inferiore laterale 1050W GT110 Side lower heating element 1050W GT110
Resist. inf. laterale 1475W UL GT140 (U.S.A.)
57 91711171
Resist. inf. laterale 1150W UL GT110 (U.S.A.)
57 91711186
58 91711165 Resistenza superiore centrale 3200W GT140 Central upper heating element 3200W GT140
58 91711195 Resistenza superiore centrale 2500W GT110 Central upper heating element 2500W GT110
58 91711180 Resist. sup. centrale 3500W UL GT140 (U.S.A.)
Resist. sup. centrale 2700W UL GT110 (U.S.A.)
58 91711185
59 91711166 Resist. sup. laterale 1600W GT140
Resist. sup. laterale 1750W UL GT140 (U.S.A.) Side upper heating element 1750W UL GT140 (U.S.A.)
59 91711181
60 91310356 Trasform. 230Vac/12Vac, 50VA, CE
60 91310357 Trasform. 230Vac/12Vac, 50VA, UL (U.S.A.-CA) Transformer 230Vac/12Vac, 50VA, UL (U.S.A.-CA)
61 92620083 Plafoniera Giotto
NOTA:
Elementi In Giallo: Ricambi per mercato Americano (U.S.A.) e Canadese (CA);
NOTE:
Components in Yellow: Spare parts for the American (U.S.A.) and Canadian (CA) markets;
HINWEIS:
Gelb markierte Elemente: Ersatzteile für den amerikanischen (U.S.A.) und den kanadischen (CA) Markt;
Giotto IT - UK - DE 01-13
- Innere Elemente
Descrizione
Single-phase safety thermostat
Contactor BF26.00
GT 140 glass 220x93
GT 110 glass 192x93
12V G5.3 connection lamp socket
G4 12V 20W 300° lamp
Ceramic-fiber for light trap door
TCJ probe for ovens L.=1,500 mm
Three-phase G10/5 terminal board
G5/12 terminal board
2T control board
Hood control board
Power board 23 A
Power board (U.S.A.-CA)
Motor inverter board
CP 2012 control panel front
D.22 red mushroom button
Fastening base
NC red contact
NO green contact
5x20F 1A Fuse
5x20F 10A Fuse
10x38 250V 1A UL Fuse (U.S.A.-CA)
10x38 250V 10A UL Fuse (U.S.A.-CA)
5x20 fuse box
10x38 UL Fuse box (U.S.A.-CA)
D.22 Joystick
2-position selector
Overload cutout switch
Bam/6 terminal board
Central lower heating element 2950W UL GT140 (U.S.A.) Unterer mittl. Heizwiderst. 2950W UL GT140 (U.S.A.)
Central lower heating element 2300W UL GT110 (U.S.A.) Unterer mittl. Heizwiderst. 2300W UL GT110 (U.S.A.)
Side lower heating element 1475W UL GT140 (U.S.A.)
Side lower heating element 1150W UL GT110 (U.S.A.)
Central upper heating element 3500W UL GT140 (U.S.A.)
Central upper heating element 2700W UL GT110 (U.S.A.)
Side upper heating element 1600W GT140
Transformer 230Vac/12Vac, 50VA, CE
Giotto ceiling light
Description
Einphasiger Sicherheitsthermostat
Schütz BF26.00
Scheibe 220x93 GT 140
Scheibe 192x93 GT 110
Glühbirnenfassung 12V mit G5,3-Sockel
Glühbirne G4 12V 20W 300°
Faserkeramik für Lichtluke
Sonde TCJ für Öfen L.=1500mm
Klemmenbrett G10/5 dreiphasig
Klemmenbrett G5/12
Kontrollkarte 2T
Kontrollkarte Abzugshaube
Leiterplatte 23A
Leiterplatte 23A (U.S.A.-CA)
Leiterplatte Motorwechselrichter
Frontblende CP 2012
Pilz-Taster D.22 rot
Befestigungsbasis
Öffnerkontakt rot
Schließerkontakt grün
Sicherung 5x20F 1A
Sicherung 5x20F 10A
Sicherung 10x38 250V 1A UL (U.S.A.-CA)
Sicherung 10x38 250V 10A UL (U.S.A.-CA)
Sicherungshalterung 5x20
Sicherungshalterung 10x38 UL (U.S.A.-CA)
Joystick D.22
Wahlschalter mit 2 Positionen
Motorschutzschalter
Klemmenbrett bam/6
Unterer mittlerer Heizwiderstand 2700W GT140
Unterer mittlerer Heizwiderstand 2100W GT110
Unterer seitlicher Heizwiderstand 1350W GT140
Unterer seitlicher Heizwiderstand 1050W GT110
Unterer seitl. Heizwiderst. 1475W UL GT140 (U.S.A.)
Unterer seitl. Heizwiderst. 1150W UL GT110 (U.S.A.)
Oberer mittlerer Heizwiderstand 3200W GT140
Oberer mittlerer Heizwiderstand 2500W GT110
Oberer mittl. Heizwiderst. 3500W UL GT140 (U.S.A.)
Oberer mittl. Heizwiderst. 2700W UL GT110 (U.S.A.)
Oberer seitl. Heizwiderst. 1600W GT140
Oberer seitl. Heizwiderst. 1750W UL GT140 (U.S.A.)
Transform. 230Vac/12Vac, 50VA, CE
Transform. 230Vac/12Vac, 50VA, UL (U.S.A.-CA)
Deckenleuchte Giotto
49
49
GT140 - GT110
Beschreibung
Q.
1
1
2
2
2
2
4
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
4
2
4
2
2
2
2
2
2
1
1
2
