CONNECTION AND CONTROL ELEMENTS

1
Connection remote lead
2
Connection ground cable
3
Connection battery cable
6
6
Loudspeaker terminals
7
CPS - Colour Protection System
8
CPS - Colour Protection System
9
Stereo/Bridged/Mono selector
1 2 3 4
4
Connection BRAX Power Stabilizer (plus)
5
Connection BRAX Power Stabilizer (minus)
7 8
9 10 11
10
Impedance selection
11
Level controls for input sensitivity
12
Signal inputs
13
Balanced signal inputs
5
13
12 6
15
