4 Mechanical installation
Arrangement of the devices
)
Note!
The place of installation and mounting material must ensure a permanent
mechanical connection.
We recommend to keep to the hole patterns of the axis modules when fixing
the DC input module. The hole spacing corresponds to device size I. For further
information, please see the Mounting Instructions for the axis module
installation backplane (EDK94ZPM113).
