ASRock 939NF4G-SATA2 Motherboard
Published August 2005
1 1 1 1 1

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für ASROCK 939NF4G-SATA2

  • Seite 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.
  • Seite 2 PCI Express x 16 Slot (PCIE1) Primary Serial ATAII Connector (SATAII_1, red) Internal Audio Connector: CD1 (Black) Chassis Speaker Header (SPEAKER 1) ATX Power Connector (ATXPWR1) Chassis Fan Connector (CHA_FAN1) Serial Port Connector (COM1) 2 2 2 2 2 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 3 TABLE for Audio Output Connection Audio Output Channels Front Speaker Rear Speaker Central / Bass Side Speaker (No. 7) (No. 4) (No. 5) (No. 3) 3 3 3 3 3 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 4: Package Contents

    In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest memory and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com...
  • Seite 5: Specifications

    Hybrid Booster - CPU Frequency Stepless Control (see CAUTION 4) - CPU Voltage - CPU Multiplier - ASRock U-COP (see CAUTION 5) - Boot Failure Guard (B.F.G.) Expansion Slot - 2 x PCI slots - 1 x PCI Express x 16 slot...
  • Seite 6 - CPU Fan Tachometer - Chassis Fan Tachometer - Voltage Monitoring: +12V, +5V, +3.3V, Vcore ® ® - Microsoft Windows 2000 / XP / XP 64-bit compliant Certifications - FCC, CE, WHQL 6 6 6 6 6 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 7 SATA hard disk (from SATAII 3Gb/s down to SATA 1.5Gb/s), and connect it to the SATAII connector. You can also connect SATA hard disk to SATAII connec- tor directly. Power Management for USB 2.0 works fine under Microsoft ® Windows ® SP1 / 2000 SP4. 7 7 7 7 7 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 8: Cpu Installation

    CPU. The lever clicks on the side tab to indicate that it is locked. Step 5. Install CPU fan and heatsink. For proper installation, please kindly refer to the instruction manuals of your CPU fan and heatsink vendors. 8 8 8 8 8 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 9 2.2 Installation of Memory Modules (DIMM) 2.2 Installation of Memory Modules (DIMM) 939NF4G-SATA2 motherboard provides four 184-pin DDR (Double Data Rate) DIMM slots, and supports Dual Channel Memory Technology. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR DIMM pair in the slots of the same color.
  • Seite 10: Installing A Dimm

    DIMM if you force the DIMM into the slot at incorrect orientation. Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends fully snap back in place and the DIMM is properly seated. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 11: Installing An Expansion Card

    (PCI Express Slots, PCI Slots and AMR Slot) (PCI Express Slots, PCI Slots and AMR Slot) There are 2 PCI Express slots, 2 PCI slots and 1 AMR slot on 939NF4G-SATA2 motherboard. PCIE Slots: PCIE1 (PCIE x 16 slot) is used for PCI Express cards with x16 lane width graphics cards.
  • Seite 12 BIOS. If you need to clear the CMOS when you just finish updating the BIOS, you must boot up the system first, and then shut it down before you do the clear-CMOS action. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 13 SA T AII_1 3.0 Gb/s data transfer rate. Serial ATA (SATA) Either end of the SATA data cable Data Cable can be connected to the SATA / SATAII hard disk or the SATAII connector on the motherboard. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 14 USB 2.0 Header ASRock 8CH I/O accommo- dates 4 default USB 2.0 ports. If (9-pin USB67) those USB 2.0 ports on the I/O (see p.2 No. 17) panel are not sufficient, this USB 2.0 header is available to...
  • Seite 15 Connect a Game cable to this header if the Game port bracket (15-pin GAME1) is installed. (see p.2 No. 23) Serial port connector This COM1 connector supports a serial port module. (9-pin COM1) (see p.2 item 32) ASRock 939NF4G-SATA2 Motherboard...
  • Seite 16 Please visit HITACHI’s website for details: http://www.hitachigst.com/hdd/support/download.htm The above examples are just for your reference. For different SATAII hard disk products of different vendors, the jumper pin setting methods may not be the same. Please visit the vendors’ website for the updates. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 17 STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk. STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII connector. STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard disk. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 18 STEP 1: Make a SATA / SATAII Driver Diskette. Insert the ASRock Support CD into your optical drive to boot your system. During POST at the beginning of system boot-up, press <F11> key, and then a window for boot devices selection appears. Please select CD- ROM as the boot device.
  • Seite 19 [Auto] to [CPU, PCIE, Async.]. Therefore, CPU FSB is untied during overclocking, but PCI and PCIE buses are in the fixed mode so that FSB can operate under a more stable overclocking environment. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 20 Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double-click on the file “ASSETUP. EXE” from the “BIN” folder in the Support CD to display the menus. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 21 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 22 ‘ ’ ™ ® ® ASRock 939NF4G-SATA2 Motherboard...
  • Seite 23 ® ® ASRock 939NF4G-SATA2 Motherboard...
  • Seite 24 ‘ ’ ™ ‘ ’ ™ ASRock 939NF4G-SATA2 Motherboard...
  • Seite 25 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 26 DDR1 DDR2 DDR3 DDR4 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 27 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 28 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 29 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 30 “ ” SAT AII_2 SA T AII_1 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 31 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 32 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 33 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 34 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 35 .. \ Information\Manual\RAID Installation Guide ASRock 939NF4G-SATA2 Motherboard...
  • Seite 36 ..\Information\Manual\RAID Utility for Windows Guide ASRock 939NF4G-SATA2 Motherboard...
  • Seite 37 ® ® ASRock 939NF4G-SATA2 Motherboard...
  • Seite 38 1. Einführung 1. Einführung 1. Einführung Wir danken Ihnen für den Kauf des ASRock 939NF4G-SATA2 Motherboard, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitätskontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.
  • Seite 39: Spezifikationen

    - Max. 4GB Hybrid Booster - Schrittloser CPU-Frequenz-Kontrolle (siehe VORSICHT 4) - CPU-Spannung - CPU-Multiplikator - ASRock U-COP (siehe VORSICHT 5) - Boot Failure Guard (B.F.G. – Systemstartfehlerschutz) Erweiterungs- - 2 x PCI -Steckplätze steckplätze - 1 x PCI Express x 16-Steckplätze - 1 x PCI Express x 1-Steckplätze...
  • Seite 40 - CPU-Überhitzungsschutz durch rechtzeitigen - Systemshutdown - Drehzahlmessung für CPU-Lüfter - Drehzahlmessung für Gehäuselüfter - Spannungsüberwachung: +12V, +5V, +3.3V, Vcore Betriebssysteme - Unterstützt Microsoft ® Windows ® 2000 / XP / XP 64-Bit Zertifizierungen - FCC, CE, WHQL ASRock 939NF4G-SATA2 Motherboard...
  • Seite 41 (von SATA II 3 GB/s auf SATA 1,5 GB/s herabstufen) und mit dem SATA II Anschluss verbinden. SATA-Festplatten können Sie auch direkt mit dem SATA II-Anschluss verbinden. Das Power Management für USB 2.0 arbeitet unter Microsoft ® Windows ® XP SP1/2000 SP4 einwandfrei. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 42: Sicherheitshinweise Vor Der Montage

    Hebel nach unten drücken, bis er hörbar einrastet. Schritt 5: Installieren Sie einen aktiven CPU-Kühler, der die gesamte Fläche der CPU abdeckt und eine ausreichende Wärmeableitung für den von Ihnen verwendeten CPU-Typ bietet. Weitere Hinweise finden Sie der Installationsanleitung für Ihren CPU-Kühler. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 43: Installation Der Speichermodule (Dimm)

    2.2 Installation der Speichermodule (DIMM) 2.2 Installation der Speichermodule (DIMM) 2.2 Installation der Speichermodule (DIMM) Die Motherboards 939NF4G-SATA2 bieten vier 184-pol. DDR (Double Data Rate) DIMM-Steckplätze und unterstützen die Dual-Kanal-Speichertechnologie. Für die Dual-Kanalkonfiguration dürfen Sie nur identische (gleiche Marke, Geschwindigkeit, Größe und gleicher Chiptyp) DDR DIMM-Paare in den Steckplätzen gleicher Farbe installieren.
  • Seite 44: Einsetzen Eines Dimm-Moduls

    Steckplätze zu zwingen, führt dies zu dauerhaften Schäden am Mainboard und am DIMM-Modul. Schritt 3: Drücken Sie die DIMM-Module fest in die Steckplätze, so dass die Halteklammern an beiden Enden des Moduls einschnappen und das DIMM-Modul fest an Ort und Stelle sitzt. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 45: Einbau Einer Erweiterungskarte

    Gigabit LAN-Karten, SATA II-Karten, usw. eingesetzt. PCI-Slots: PCI-Slots werden zur Installation von Erweiterungskarten mit dem 32bit PCI-Interface genutzt. AMR-Slot: Der AMR-Steckplatz dient zur Aufnahme der ASRock MR-Karte (Option) mit v.92 Modem-Funktionalität. Einbau einer Erweiterungskarte Einbau einer Erweiterungskarte Einbau einer Erweiterungskarte...
  • Seite 46: Einstellung Der Jumper

    CMOS gelöscht wurde. Bitte vergessen Sie nicht, den Jumper wieder zu entfernen, nachdem das CMOS gelöscht wurde. Wenn Sie den CMOS- Inhalt gleich nach dem Aktualisieren des BIOS löschen müssen, müssen Sie zuerst das System starten und dann wieder ausschalten, bevor Sie den CMOS-Inhalt löschen. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 47 Diese beiden Serial ATA Seriell-ATAII-Anschlüsse (SATA II) -Anschlüsse (SATAII_1: siehe S.2, Punkt 13) unterstützen interne SATA- SA T AII_2 (SATAII_2: siehe S.2, Punkt 12) oder SATA II-Festplatten. Die aktuelle SATAII-Schnittstelle ermöglicht eine SA T AII_1 Datenübertragungsrate bis 3,0 Gb/s. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 48 Netzteil das weiße Ende des SATA- Stromversorgungskabels mit dem Stromanschluss des Netzteils. USB 2.0-Header ASRock 8CH I/O (E/A) verfügt über 4 Standard-USB 2.0- (9-pol. USB67) Anschlüsse auf der Rückseite. (siehe S.2 - Nr. 17) Wenn die hinteren USB- Anschlüsse nicht ausreichen, steht dieser USB 2.0-Header...
  • Seite 49 Verbinden Sie das CPU - Lüfterkabel mit diesem (3-pin CPU_FAN1) Anschluss und passen Sie den (siehe S.2, Punkt 10) schwarzen Draht dem Erdungsstift an. ATX-Netz-Header Verbinden Sie die ATX- Stromversorgung mit diesem (20-pin ATXPWR1) Header. (siehe S.2, Punkt 31) ASRock 939NF4G-SATA2 Motherboard...
  • Seite 50 System zu starten. Game-Anschluss Verbinden Sie ein Game-Kabel Anschluss, wenn diesem (15-pin GAME1) der Game-Anschlusshalter (siehe S.2, Punkt 23) installiert ist. COM-Anschluss-Header Dieser COM-Anschluss- Header wird verwendet, um (9-pin COM1) ein COM-Anschlussmodul zu (siehe S.2 - No. 32) unterstützen. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 51 DOS ausführbares Dienstprogramm. Auf der Internetseite von HITACHI finden Sie entsprechende Details: http://www.hitachigst.com/hdd/support/download.htm Die Beispiele oben dienen lediglich Ihrer Referenz. Die Steckbrückeneinstellungen können bei unterschiedlichen SATA II Festplatten verschiedener Hersteller abweichen. Aktualisierungen und ergänzende Informationen finden Sie auf der Internetseite des Herstellers. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 52 SCHRITT 2: Verbinden Sie das SATA-Netzkabel mit der SATA / SATAII-Festplatte. SCHRITT 3: Schließen Sie ein Ende des SATA-Datenkabels am SATA / SATAII- Anschluss des Motherboards an. SCHRITT 4: Schließen Sie das andere Ende des SATA-Datenkabels an die SATA / SATAII-Festplatte an. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 53 SCHRITT 1: Erstellen Sie eine SATA / SATAII-Treiberdiskette. Legen Sie die ASRock Support-CD in Ihr optisches Laufwerk, um Ihr System hochzufahren. (Legen Sie zu diesem Zeitpunkt KEINE Diskette in das Diskettenlaufwerk ein!) Während des Selbsttests zu Beginn des Systemstarts drücken Sie die <F11>- Taste –...
  • Seite 54: Entkoppelte Übertaktungstechnologie Entkoppelte Übertaktungstechnologie (Untied Overclocking T (Untied Overclocking Technology) (Untied Overclocking T Echnology)

    Bevor Sie die Entkoppelte Übertaktung aktivieren, stellen Sie bitte die Option “Overclock Mode” (Übertaktungsmodus) im BIOS von [Auto] auf [CPU, PCIE, Async.] um. Dadurch wird der CPU-FSB beim Übertakten entkoppelt, PCI- und PCIE-Busse werden jedoch fixiert, so dass der FSB in einer stabileren Übertaktungsumgebung arbeiten kann. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 55 ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menügesteuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 56 1. Introduction Merci pour votre achat d’une carte mère ASRock 939NF4G-SATA2, une carte mère très fiable produite selon les critères de qualité rigoureux de ASRock. Elle offre des performances excellentes et une conception robuste conformément à l’engagement d’ASRock sur la qualité et la fiabilité au long terme.
  • Seite 57: Spécifications

    - Contrôle direct de la fréquence CPU (voir ATTENTION 4) hybride - Voltage du CPU - Multiplicateur du CPU - ASRock U-COP (voir ATTENTION 5) - Garde d’échec au démarrage (B.F.G.) Slot d’extension - 2 x slots PCI - 1 x slot PCI Express x 16...
  • Seite 58 CPU - Tachéomètre ventilateur CPU - Tachéomètre ventilateur châssis - Monitoring de la tension: +12V, +5V, +3.3V, Vcore - Microsoft ® Windows ® 2000 / XP / XP 64-bit Certifications - FCC, CE, WHQL ASRock 939NF4G-SATA2 Motherboard...
  • Seite 59 SATA 1.5 Go/s) et de le brancher sur le connecteur SATAII. Vous pouvez également brancher le disque dur SATA directement sur le connecteur SATAII.. La gestion de l’alimentation pour l’USB 2.0 fonctionne bien sous ® ® Microsoft Windows XP SP1/2000 SP4. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 60 CPU. Le verrouillage du levier dans son encoche latérale est annoncé par un clic. Etape 5. Installez le ventilateur et le radiateur du CPU. Pour une installation correcte, reportez-vous aux manuels du fabricant du ventilateur et du radiateur de CPU. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 61 2.2 Installation des modules m émoire [DIMM] 2.2 Installation des modules m émoire [DIMM] La carte mère 939NF4G-SATA2 dispose de quatre emplacements DIMM DDR (Double Data Rate) de 184-broches, et supporte la Technologie de Mémoire à Canal Double. Pour effectuer une configuration à canal double, vous devez toujours installer des paires de DIMM DDR identiques (de la même marque, de la...
  • Seite 62 DIMM. Etape 3. Insérez fermement le module DIMM dans son emplacement jusqu’à ce que les clips de maintien situés aux deux extrémités se ferment complètement et que le module DIMM soit inséré correctement. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 63 Slots PCI: Les slots PCI sont utilisés pour installer des cartes d’extension dotées d’une interface PCI 32 bits. Slot AMR: Le slot AMR est utilisé pour insérer une carte ASRock MR (optionnelle) avec des fonctionnalités Modem v.92. Installation d’une carte d’extension Installation d’une carte d’extension...
  • Seite 64 BIOS à jour. Si vous avez besoin d’effacer la CMOS lorsque vous avez fini de mettre le BIOS à jour, vous devez d’abord initialiser le système, puis le mettre hors tension avant de procéder à l’opération d’effacement de la CMOS. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 65 SATA ou SATAII (SATAII_2: voir p.2 fig. 12) SA T AII_2 pour les dispositifs de stockage interne. L’interface SATAII SA T AII_1 actuelle permet des taux transferts de données pouvant aller jusqu’à 3,0 Go/s. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 66 électrique SATA sur le connecteur d’alimentation de l’unité d’alimentation électrique. En-tête USB 2.0 L’ASRock 8CH I/O (E/S ASRock 8CH) vous fournit 4 ports USB (USB67 br.9) 2.0 par défaut situés sur le (voir p.2 No. 17) panneau arrière. Si les ports USB arrières ne sont pas...
  • Seite 67 électrique avec (ATX12V1 br. 4) prise ATX 12V sur ce (voir p.2 fig. 2) connecteur afin d’avoir une alimentation suffisante. Faute de quoi, il ne sera pas possible de mettre sous tension. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 68 (GAME1 br. 15) port jeux est installée. (voir p.2 fig. 23) En-tête de port COM Cette en-tête de port COM est utilisée pour prendre en charge (COM1 br.9) un module de port COM. (voir p.2 No. 32) ASRock 939NF4G-SATA2 Motherboard...
  • Seite 69 Pour les différents produits disques durs SATAIII provenant de différents vendeurs, les méthodes de mise en place de cavaliers ne sont pas les mêmes. Veuillez visiter le site Internet des vendeurs pour les mises à jours. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 70 ETAPE 3 : Connectez l’une des extrémités du câble de données SATA sur le connecteur SATAII de la carte mère. ETAPE 4 : Connectez l’autre extrémité du câble de données SATA au disque dur SATA / SATAII. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 71 : http://www.microsoft.com/Windows2000/downloads/servicepacks/sp4/ spdeploy.htm#the_integrated_installation_fmay ETAP 1: Créez une disquette pilotes SATA / SATAII. A. Insérez le CD de soutien ASRock dans votre lecteur de disque optique pour démarrer votre système. (N’insérez AUCUNE disquette dans le lecteur de disquette pour l’instant!) B. Pendant le POST au début du démarrage du système, appuyez sur la touche <F11>, et une fenêtre s’affiche pour la sélection des périphériques de démarrage.
  • Seite 72 [Auto] à [CPU, PCIE, Async.]. Par conséquent, le CPU FSB n’est pas lié durant le surcadençage, mais les bus PCI et PCIE sont en mode fixé de sorte que FSB peut opérer sous un environnement de surcadençage plus stable. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 73 Pour utiliser le CD technique, insérez-le dans le lecteur de CD-ROM. Le Menu principal s’affiche automatiquement si “AUTORUN” est activé dans votre ordinateur. Si le Menu principal n’apparaît pas automatiquement, localisez dans le CD technique le fichier “ASSETUP.EXE” dans le dossier BIN et double-cliquez dessus pour afficher les menus. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 74 Grazie per aver scelto una scheda madre ASRock 939NF4G-SATA2, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza. Questa Guida Rapida all’Installazione contiene l’introduzione alla motherboard e la guida passo-passo all’installazione.
  • Seite 75 Booster ibrido - Stepless control per frequenza del processore (vedi ATTENZIONE 4) - Voltaggio CPU - Moltiplicatore CPU - ASRock U-COP (vedi ATTENZIONE 5) - Boot Failure Guard (B.F.G.) Slot di - 2 x slot PCI espansione - 1 x slot PCI Express x 16...
  • Seite 76 - Indicatore di velocità per la ventola del processore - Indicatore di velocità per la ventola di raffreddamento - Voltaggio: +12V, +5V, +3.3V, Vcore Compatibi- - Microsoft ® Windows ® 2000 / XP / XP 64 bit lità SO Certificazioni- FCC, CE, WHQL ASRock 939NF4G-SATA2 Motherboard...
  • Seite 77 SATAII a disco rigido SATA (da SATA II 3Gb/s a SATA 1.5Gb/s) e collegarlo al connettore SATAII. Si può anche connettere il disco rigido SATA al connettore SATAII direttamente. ® La Gestione Risorse per USB 2.0 funziona perfettamente con Microsoft Windows ® XP SP1/2000 SP4. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 78: Installazione

    Quando la leva fa clic sulla linguetta laterale significa che è bloccata. Step 5. Installare la ventola del processore e l’heatsink. Per una corretta installazione, per favore fare riferimento ai manuali di istruzione dei produttori della ventola e dell’heatsink del processore. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 79 2.2 Installazione dei moduli di memoria (DIMM) 2.2 Installazione dei moduli di memoria (DIMM) La scheda madre 939NF4G-SATA2 fornisce quattro alloggiamenti DIMM DDR (Double Data Rate) a 184 pin, e supporta la tecnologia Dual Channel Memory. Per la configurazione a due canali, è necessario installare sempre coppie identiche (stessa marca, velocità, dimensioni e tipo di chip) di DIMM DDR negli alloggiamenti...
  • Seite 80 DIMM stessa. Step 3. Inserire saldamente la DIMM nello slot fino a far scattare completamente in posizione i fermagli di ritegno alle due estremità e fino ad installare correttamente la DIMM nella sua sede. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 81 (Slot PCI Express, Slot PCI ed Slot AMR) (Slot PCI Express, Slot PCI ed Slot AMR) Sulla scheda madre 939NF4G-SATA2 c’è 2 slot PCI Express, 2 slot PCI ed 1 slot AMR. Slot PCI Express: PCIE1 (slot PCIE x16) usato per schede PCI Express con schede grafiche di larghezza x16.
  • Seite 82 Non cancellare la CMOS subito dopo aver aggiornato il BIOS. Se è necessario cancellare la CMOS una volta completato l’aggiornamento del BIOS, è necessario riavviare prima il sistema, e poi spegnerlo prima di procedere alla cancellazione della CMOS. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 83 SA T AII_2 HD SATA o SATAII per le funzioni di archiviazione interna. ATAII (SATAII) suppo- SA T AII_1 rtano cavi SATAII per dispositivi di memoria interni. L’interfaccia SATAII attuale permette velocità di trasferimento dati fino a 3.0 Gb/s. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 84 SATA al connettore power dell’alimentatore. Collettore USB 2.0 Il dispositivo ASRock 8CH I/O mette a vostra disposizione 4 (9-pin USB67) porte USB 2.0 di default sul (vedi p.2 No. 17) pannello posteriore. Se le porte USB posteriori non sono sufficienti, è...
  • Seite 85 (vedi p.2 item 31) Connettore ATX 12V È necessario collegare una alimentazione con spinotto da (4-pin ATX12V1) 12V ATX a questo connettore (vedi p.2 item 2) in modo che possa fornire energia sufficiente. In caso contrario l’unità non si avvia. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 86 Connettere un cavo Game a questo connettore solo se la (15-pin GAME1) porta giochi è installata. (vedi p.2 item 23) Collettore porta COM Questo collettore porta COM è utilizzato per supportare il (9-pin COM1) modulo porta COM. (voir p.2 Nr. 32) ASRock 939NF4G-SATA2 Motherboard...
  • Seite 87 Gli esempi di cui sopra sono solo per riferimento. Per dischi rigidi SATAII di diversi produttori, i metodi di impostazione dei pin del jumper possono non essere gli stessi. Visitare i siti web dei produttori per gli aggiornamenti. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 88 SATA / SATAII senza funzioni RAID, non è necessario creare un dischetto driver SATA / SATAII. Inoltre, non è necessario modificare le impostazioni del BIOS. È possibile iniziare l’installazione di Windows 2000, Windows XP o Windows XP 64 bit direttamente sul sistema. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 89 1° PASSO: Creare un dischetto driver SATA / SATAII. Inserire il CD di supporto ASRock nel lettore ottico prima di accendere il sistema. (NON inserire nessun dischetto floppy nel drive in questo momento!) Durante la fase di POST, all’inzio del boot-up del sistema, premere il tasto <F11>.
  • Seite 90 [Auto] a [CPU, PCIE, Async.]. A questo punto, la CPU FSB è “libera” durante l’overclocking, ma i bus PCI e PCIE sono nella modalità fissata in modo tale che l’FSB posa operare sotto un più stabile ambiente di overclocking. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 91 Inserire il CD di supporto nel lettore CD-ROM. Se la funzione “AUTORUN” è attivata nel computer, apparirà automaticamente il Menù principale. Se il Menù principale non appare automaticamente, posizionarsi sul file ASSETUP. EXE nel CESTINO del CD di supporto e cliccare due volte per visualizzare i menù. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 92 1. Introducción 1. Introducción Gracias por su compra de ASRock 939NF4G-SATA2 placa madre, una placa de confianza producida bajo el control de calidad estricto y persistente. La placa madre provee realización excelente con un diseño robusto conforme al compromiso de calidad y resistencia de ASRock.
  • Seite 93 - Stepless control de frecuencia de CPU (vea ATENCIÓN 4) Híbrido - Voltaje de CPU - Multiplicador de CPU - ASRock U-COP (vea ATENCIÓN 5) - Protección de Falla de Inicio (B.F.G..) Ranuras de - 2 x ranuras PCI Expansión...
  • Seite 94 - Taquímetros de los ventiladores del procesador y del chasis - Monitor de Voltaje: +12V, +5V, +3.3V, Vcore ® ® - En conformidad con Microsoft Windows 2000 / XP / XP 64 bits Certificaciones - FCC, CE, WHQL ASRock 939NF4G-SATA2 Motherboard...
  • Seite 95 SATAII a disco duro SATA (de SATAII 3Gb/s a SATA 1.5 Gb/s) y conectarlo al conector SATAII. También puede conectar el disco duro SATA al conector SATAII directamente. ® ® Power Management para USB 2.0 funciona bien bajo Microsoft Windows XP SP1/2000 SP4. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 96: Instalación

    CPU, examine su orientación o examine si los pins están ya encorvados. Paso 4. Encierre el zócalo bajando la palanca. Paso 5. Instale el disipador de calor con ventilador del CPU ( consulte la documentación del disipador de calor). ASRock 939NF4G-SATA2 Motherboard...
  • Seite 97 2.2 Instalación de Memoria 2.2 Instalación de Memoria La placa 939NF4G-SATA2 ofrece cuatro ranuras DIMM DDR de 184 pines, y soporta Tecnología de Memoria de Doble Canal. Para la configuración de doble canal, necesitará instalar siempre pares DIMM DDR idénticos (de la misma marca, velocidad, tamaño y tipo) en las ranuras del mismo color.
  • Seite 98 DIMM. Paso 3. Inserte la DIMM con firmeza dentro de la ranura hasta que los clips de sujeción de ambos lados queden completamente introducidos en su sitio y la DIMM se haya asentado apropiadamente. ASRock 939NF4G-SATA2 Motherboard...
  • Seite 99 PCI Express, ranuras PCI y ranuras AMR) ranuras PCI Express, ranuras PCI y ranuras AMR) ranuras PCI Express, ranuras PCI y ranuras AMR) La placa madre 939NF4G-SATA2 cuenta con 2 ranuras PCI Express, 2 ranuras PCI y 1 ranuras AMR. Ranura PCI Express: PCIE1 (ranura PCIE x16) se utiliza para tarjetas PCI Ex press con tarjetas gráficas con una anchura de 16...
  • Seite 100 CMOS cuando acabe de finalizar la actualización de la BIOS, debe arrancar primero el sistema y, a continuación, apagarlo antes de realizar la acción de borrado de CMOS. 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 101 Ambos extremos del cable serie ATA (SATA) pueden conectarse al disco duro SATA / SATAII o la conexión de la placa base. 1 0 1 1 0 1 1 0 1 1 0 1 1 0 1 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 102 SATA a la conexión de alimentación de la fuente de alimentación. Cabezal USB 2.0 ASRock 8CH I/O le proporciona 4 puertos USB 2.0 (9-pin USB67) predeterminados en el panel (ver p.2, No. 17) posterior. Si los puertos USB posteriores no son suficientes, este cabezal USB 2.0 (USB67)
  • Seite 103 (vea p.2, No. 2) con el enchufe ATX 12V, de modo que proporcione suficiente electricidad. De lo contrario no se podrá encender. 1 0 3 1 0 3 1 0 3 1 0 3 1 0 3 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 104 Cabezal del puerto COM Este cabezal del puerto COM se utiliza para admitir un (9-pin COM1) módulo de puerto COM. (vea p.2, N. 32) 1 0 4 1 0 4 1 0 4 1 0 4 1 0 4 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 105 Por favor visite el sitio Web de los proveedores para obtener las actualizaciones. 1 0 5 1 0 5 1 0 5 1 0 5 1 0 5 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 106 SATA / SATAII. Además, no necesita cambiar la configuración BIOS. Puede comenzar a instalar Windows 2000, Windows XP o Windows XP 64 bits en su sistema directamente. 1 0 6 1 0 6 1 0 6 1 0 6 1 0 6 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 107 PASO 1: Haga un Disquete de Controlador SATA / SATAII. Inserte el CD de soporte de ASRock en la unidad óptica de la unidad para iniciar el sistema. (NO inserte ningún disquete en la unidad de disco en este momento) Durante la comprobación inicial (POST) del sistema, pulse la tecla <F11>...
  • Seite 108 PIC y PCIE están en el modo fijo de manera que FSB puede operar bajo un ambiente de forzado de reloj más estable. 1 0 8 1 0 8 1 0 8 1 0 8 1 0 8 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 109 Principal automáticamente si «AUTORUN» está habilitado en su computadora. Si el Menú Principal no aparece automáticamente, localice y doble-pulse en el archivo ASSETUP.EXE para iniciar la instalación. 1 0 9 1 0 9 1 0 9 1 0 9 1 0 9 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 110 Gratos por comprar nossa placa–mãe 939NF4G-SATA2, um produto confiável feito com ASRock um estrito controle de qualidade consistente. Com um excelente desempenho, essa placa é dotada de um projeto robusto que atende a ASRock de compromisso com a qualidade e durabilidade.
  • Seite 111 (veja o AVISO 4) - Voltagem da CPU - Multiplicador da CPU - ASRock U-COP (veja o AVISO 5) - B.F.G. (Boot Failure Guard) Slots de Expansão - 2 x slots de PCI - 1 x slots de PCI Express x 16...
  • Seite 112 - Monitoramento de voltagem : +12 V, +5 V, +3.3 V, Vcore ® ® Sistema - Microsoft Windows 2000 / XP / XP 64-bit Operacional Certificações - FCC, CE, WHQL 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 113 SATAII. Também pode ligar directamente o disco duro SATA ao conector SATAII. Power Management para USB 2.0 funciona bem embaixo de Microsoft ® ® Windows XP SP1/2000 SP4. 1 1 3 1 1 3 1 1 3 1 1 3 1 1 3 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 114 CPU e o dissipador de calor. Para fazer uma instalação correta, consulte antes os manuais de instrução dos fabricantes da CPU e do dissipador de calor. 1 1 4 1 1 4 1 1 4 1 1 4 1 1 4 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 115 2.2 Instalação dos Módulos de Memória (DIMM) 2.2 Instalação dos Módulos de Memória (DIMM) A 939NF4G-SATA2 possui quatro slots DIMM DDR (taxa de dados dupla) de 184 pinos e suporta a tecnologia de memória de duplo canal. Para a configuração de duplo canal, instale sempre um par idêntico de DIMM DDR (mesma marca, tipo, tamanho...
  • Seite 116 Insira a DIMM firmemente no slot até que os clipes de retenção em ambos os lados se encaixem totalmente em seus locais e a DIMM esteja encaixada de modo apropriado. 1 1 6 1 1 6 1 1 6 1 1 6 1 1 6 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 117 Os slots PCI se usam para instalar placas de expansão com uma interface de PCI de 32 bit. Slot AMR: O slot AMR é utilizado para inserir o cartão MR ASRock (opcional) com funcionalidade v.92 de modem. Instalando uma placa de expansão Instalando uma placa de expansão...
  • Seite 118 CMOS ao concluir a atualização do BIOS, deverá reiniciar o sistema primeiro e, em seguida, desligá-lo antes de executar a ação de limpeza o CMOS. 1 1 8 1 1 8 1 1 8 1 1 8 1 1 8 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 119 Tanto a saída do cabo de Serial ATA (SATA) dados SATA pode ser conectado ao disco rígido SATA / SATAII quanto o conector SATAII na placa mãe. 1 1 9 1 1 9 1 1 9 1 1 9 1 1 9 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 120 SATA ao conector de alimentação da fonte. Cabezal USB 2.0 ASRock 8CH I/O le proporciona 4 puertos USB 2.0 (9-pin USB67) predeterminados en el panel (ver p.2, No. 17) posterior. Si los puertos USB posteriores no son suficientes, este cabezal USB 2.0 (USB67)
  • Seite 121 (ATX12V1 de 4 pinos ) conector ATX 12V neste (veja a folha 2, No. 2) conector para fornecer alimentação suficiente. Do contrário, haverá falhas de funcionamento. 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 122 Conector da porta COM Este conector é usado para suportar um módulo de porta (COM1 de 9 pinos) COM. (veja a folha 2, No. 32) 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 123 SATAII ou diferentes vendedores, os métodos de definição dos pinos jumper poderão não ser os mesmos. Por favor visite o sítio Web do vendedor para actualizações. 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 124 Conecte uma extremidade do cabo de dados SATA ao conector SATAII da placa-mãe. º passo: Conecte a outra extremidade do cabo de dados SATA ao disco rígido SATA / SATAII. 1 2 4 1 2 4 1 2 4 1 2 4 1 2 4 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 125 ETAPA 1: Crie uma disquete com o controlador SATA / SATAII. Insira o CD ASRock Support no acionador ótico para reiniciar seu sistema. (NÃO insira nenhum disquete no acionador de disquete neste momento!) Durante o POST no início do boot do sistema, tecle o botão <F11>...
  • Seite 126 PCIE e PCI permanecem fixos para que o FSB possa funcionar num ambiente de overclocking mais estável. 1 2 6 1 2 6 1 2 6 1 2 6 1 2 6 ASRock 939NF4G-SATA2 Motherboard...
  • Seite 127 Automaticamente iniciará o menu principal, casa o “AUTORUN” esteja ativado. Se o menu principal não aparecer automaticamente, explore o CD e execute o “ASSETUP. EXE” localizado na pasta “BIN”. 1 2 7 1 2 7 1 2 7 1 2 7 1 2 7 ASRock 939NF4G-SATA2 Motherboard...
