Maxwell 25624 Anwendungsinformation Seite 3

Function Range
400 mVDC
4 VDC
DC voltage 40 VDC
400 VDC
600 VDC
400 mVAC
4 VAC
AC voltage 40 VAC
400 VAC
600 VAC
400 Ω
4 kΩ
40 kΩ
Resistance
400 kΩ
4 MΩ
40 MΩ
Function Range
5 Hz
50 Hz
500 Hz
Frequency
5 kHz
50 kHz
100 kHz
0.5 - 99.0%
Duty cycle
Width:100μs-100ms,
Frequency: 5Hz-100kHz
AC Watt
0-250V, 0-400A 40 kW
50/60Hz TRMS
AC Watt
0-600V, 0-400A 240 kW
50/60Hz TRMS
Accuracy(% read
value)
± (1.5% + 3 digit)
± (2.0% + 3 digit)
± (0.8% + 20 digit)
± (1.8% + 5 digit)
± (2.5% + 5 digit)
± (1.0% + 4 digit)
± (1.5% + 2 digit)
± (2.5% + 3 digit)
± (3.5% + 5 digit)
Accuracy (%
read value)
± (1.5% + 5
digit)
± (1.2% + 2
digit)
Sensitivity:
10 V RMS
min.
± (1.2% + 2
digit)
± (2.5% + 5
digit)
± (2.5% + 5
digit)
Function Range
DC Watt 0-250V,
40 kW
0-400A
DC Watt 0-250V,
240 kW
0-400A
appr. 1.2" (30mm) when
Clamp size
open
current 0.3mA; open
Diode test
circuit voltage 1.5V DC
threshold <100Ω; test
Continuity
current < 1mA
Low battery
" BAT " is displayed
indicator
Overload
" OL " is displayed
Measuring time
2 seconds
Input 7.8MΩ (VDC and ADC)
Display
4 digit LCD
AC current
50/60Hz true RMS (AAC)
AC voltage
50/60Hz true RMS (VAC)
bandwidth
Operating
14-122°F (-10-50°C)
temperature
Storage
-14-140°F (-30-60°C)
temperature
90% (0°C-30°C); 75%
Relative
(30°C-40°C);
humidity
45% (40°C-50°C)
operating: 3.000m;
Altitude
storage: 10.000m
High voltage
Category III. 600V
Battery 9V
Automatic turn
appr. 35 min
off
Dimensions /
229 x 80 x 49mm / 303g
weight
EN
User Manual
Accuracy (%
read value)
± (2.0% + 5
digit)
± (2.0% + 5
digit)
