2.
From the ADSL Standard drop-down list, select G.dmt, G.lite, T1.413, or
Multi-Mode. In most cases, the default setting of Multi-Mode is sufficient.
You may want to check with your ISP to confirm the correct settings. Once
you have made your selection, click Apply.
3.
Click the Next button in the lower right corner of the screen to move to the
WAN Setup page.
Configure Service Provider Settings
In the Service Provider Settings/WAN Setup screen, enter the values obtained
from your ISP. See the User Guide's ISP Settings Table for popular ISP settings.
(Settings may vary from the table listing. Check with your ISP.) If you don't find
your ISP on the table, call your ISP to obtain settings.
1.
See the Current ATM PVC List at the bottom of the screen. On this list,
delete any connection type that you don't need.
2.
Select the connection type recommended by your ISP. Choose mode
RFC1483 bridged, RFC 1483 routed, PPPoE, PPPoA or MER. Some connec-
tion types may require additional information, such as IP address or user-
name and password.
3.
At the top of the WAN Setup Screen, fill in the VPI and VCI values.
Select the Encapsulation mode. Click either the LLC/SNAP or VC Multi-
4.
plexing radio button.
5.
If appropriate, check the Network Settings box entitled "Enable NAPT."
6.
If appropriate, check the Network Settings box entitled "Enable DHCP."
7.
Click the Add button.
8.
To continue, click the Next button in the lower right corner of the screen.
10
