Special installation instructions
Volvo / Land Rover / Range Rover with component protection by
serial number query:
Head unit
Before removing the OEM amplifier, first its serial number must be cop-
ied into the SDMI25, proceed as follows:
1. Remove all three jumpers from the SDMI25 (see page 15, item 4).
2. Install SDMI25 in the MOST bus when the system is switched off
(see page 21, point 4, 5 and 7).
IMPORTANT: The OEM amplifier must be installed at the same time.
For this purpose an optional MOST fibre-optic Y-cable is required for
installation (see the following picture).
22
OEM module
IN OUT
copies serial number
OUT
IN
SDMI25
OEM amplifier
OEM module
OUT
IN
