3 Optical Out
Optical, digital stereo signal output in SPDIF format for connecting sig-
nal processors or amplifiers with DSP. The output provides a volume
controlled signal and has a sampling rate of 48 kHz / 24 Bit.
Note: This output solely provides a stereo signal. Multi-channel sur-
round sound formats such as Dolby or DTS are not supported!
4 Jumper
These jumpers must be used to configure the SDMI25 to the individual
car model. Therefore plug the jumpers to the appropriate positions. An
overview of the jumper configurations can be found on page 18.

Technical Data

Input............................................. 1 x MOST25
Output .......................................... 1 x Optical SPDIF (48 kHz / 24 Bit)
Frequency response .................... 10 - 22,000 Hz
Operating voltage ........................ 9.6 - 18 Volts (5 sec. down to 6 Volts)
Dimensions (H x W x D) .............. 34.60 x 62 x 102 mm
1.36 x 2.44 x 4.02"
17
