3 Assembly

3.1 Assembly of two suction arms

Both arms are comprised of the following three main components:
- The rotary rim;
- The load-bearing frame;
- The suction hood.
Each of the components is always packed in a separate box.
The box with the load-bearing frame contains the User Manual and arrangement of
the suction arms. Follow the manual to install the suction arms on a carriage.

4 Operation

4.1 Position of suction arms

The 2-arm ProfiMaster devices and both suction arms must be arranged in such a
way that each of the arms points to a different direction, in relation to the welding
station.
Otherwise, stability of the device may be reduced, depending on the length and
position of the arms.
The worst-case scenario is that the device will overturn.
CAUTION
There is a risk of injury, if the 2-arm ProfiMaster device is overturned.
Furthermore, the 2-arm ProfiMaster device can be damaged!
Incorrect position of the suction arms may result in tilting and overturning
of the filtration device!

4.2 The Start-Stop Mode

Install the start-stop sensor, if it is intended for the 2-arm ProfiMaster device to
operate in the Start-Stop Mode.
To this end, connect ground cables of both welding machines to the Start-Stop
sensor, if the 2-arm ProfiMaster device is used.
Art. No. 150 2487
We reserve the right to introduce technical modifications and make errors.
KEMPER 2-arm ProfiMaster
Extension to the User Manual – EN
- 13 - Version: 0
Valid as of: June 2015
