3. Layout & Connections

3.1 Layout

Front:
1x USB 3.1 (Gen1)
Downstream A-Port
Back:

3.2 Connections

+19V - 20V T-Block:
GND (Ground)
+19V - 20V
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
1x USB 3.1 (Gen1)
Downstream C-Port
with PD Charging
1x USB 3.1 (Gen1)
Upstream C-Port
with PD Charging
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
9
2x USB 3.1 (Gen1)
Downstream A-Port
Power LED
19-20V T-Block
for optional external
Power Supply
English
19-20V Connector
for included external
Power Supply
