1. Description

The EX-1190HMVS-PD is a plug & play high-speed USB 3.1 (Gen1) metal hub for 4
USB devices. The EX-1190HMVS-PD provides 4 ports for USB devices and 1 uplink
port for PC. It supports all USB connections from 1.1 to 3.1. All ports can fix with screw
lock. Via a external power supply it is possible to load the host PC via the USB-C up-
stream port and a device via the USB-C downstream port. The USB-A ports provide up
to 2A. This allows you charging an iPhone, iPad, Smartphone and Tablet. The EX-
1190HMVS-PD design fully utilize the Genesys chipset, which represents the latest in
SuperSpeed USB interface technology. It uses data transfer rates up to 5Gbit/s. It pro-
vides a secure and very high data transfer on each single port. The EX-1190HMVS-PD
support the Self Powered and Bus Powered mode. In addition the EX-1190HMVS-PD is
equipped with an 15KV ESD surge protection.
Features:
•
Compatible for USB 1.1, 2.0, 3.0 & 3.1
•
Up to 5Gbit/s
•
All Operating Systems are supported
•
All ports are Screw Lock
•
15KV ESD Surge Protection
•
PD support Power Source: 20V/5A, 14,5V/2A, 12V/3A and 5V/3A
•
Certificate for

2. Extent of Delivery

Before you connect the EX-1190HMVS-PD to your PC, you should first check the con-
tents of the delivery:
•
EX-1190HMVS-PD
•
Power Supply (19V/2,64A)
•
USB 3.1 (Gen1) Cable
•
Manual
