WARNING DEVICE LAL-SRW3
Installation
EN
20 - EN
Connecting and configuring the warning device with overflow sensor and
oil level sensor
1
bn bu bn bu
13 15 22 24
18 20
1 2 3 5 6 7 10 11 12
6 4
230 V AC
Figure 3.9
1 Overflow sensor connection
2 Oil level sensor connection
3 Overflow sensor NVF-104/34-PF
4 Oil level sensor KVF-104-PF
5 DIP switches
6 Power supply
bu blue
bn brown
2
5 3
1 2 3 4 5 6 7 8
OFF
ON
4 3
