Operating FRITZ!Powerline 540E Manually
FRITZ!Powerline 540E has three buttons for manual operation and to display the
operating status.
Operation
press briefl y
LED On/Off
on
fl ashes
off
press briefl y
reset
on
fl ashes
off
press briefl y
12
Condition
LEDs can be switched on and off
WLAN function is enabled
WPS quick connection in progress
WLAN function is switched off
Starting a WPS quick connection
for factory settings, press and hold at the same
time as
Connected in the powerline network
Connecting, or not in the powerline network
Powerline is switched off on the adapter
Integrating FRITZ!Powerline safely into an existing
powerline network
The FRITZ!Powerline 510E Status Display
FRITZ!Powerline 510E displays the following operation statuses:
Condition
Power on
fl ashes
fl ashes intermittently
(every 15s)
off
LAN on
off
Powerline on
off
FRITZ!Powerline 510E
has electrical power
is restarting or confi guring security settings
is on standby
has no electrical power
the LAN port is in use
no LAN cable is connected or the device on the LAN
cable is switched off
is connected with the powerline network and ready
for data exchange
did not detect any compatible powerline devices
or did not detect any devices that use the same
network key
