MICROPHONE
20. PTT key: trasmission button
21. UP key
22. DOWN key
INSTALLATION
Select the mounting location so that road safety is not affected by the device, or
additional risk of injury in an accident arises. Check that the display can be seen, and
the controls can easily accessed.

POWER SUPPLY

Fuse
A fuse in the power cable protects against damage caused by technical defects or
incorrect polarity. If this fuse is blown, first eliminate the error and then replace
the blown fuse for DC power Cord, use F3A 250V type.The parameters and the
symbol of the fuse are indicated in the following label.
If the fuse burns several times, please send the radio to our service.
M-Mini Instruction Guide
F3A 250V +
22
DOWN
20
21
UP
| 5
T
R
1
