5.6

Current Measurement

Ensure that the measurement circuit is not live when connecting the
measurement instrument.
The instruments may only be used in current circuits protected at 16A
up to a nominal voltage of 600 V.
The nominal cross section of connecting line has to be respected and a
safe connection has to be ensured.
After instrument fuse tripping eliminate the cause for the tripping prior
to fuse replacement..
Current Measurement 200 mA
Position measurement function selection switch to A
A 200m measurement range..
Connect the black test lead to the COM socket and the red test lead to
the
Connect test leads to UUT.
Read the measurement result displayed on the screen.
Current Measurement 15 A
Position measurement function selection switch to A
15 measurement range.
Connect the black test lead to the COM socket and the red test lead to
the 15 A socket.
Connect test leads to UUT.
Read the measurement result displayed on the screen.
38
socket.
200m or
15 or A
