- Seite 1 ALNO Bedienungs- und Einbauanleitung Einbau-Kühl- Gefrierkombination AKE 8220 IW ® ... die Welt der Küche 2222 350-11...
- Seite 2 English Warnings It is most important that this instruction book should be retained with the appli- ance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings.
- Seite 3 This appliance is heavy. Care should be taken when moving it. Ice lollies can cause frost burns if consumed straight from the appliance. This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians. Never use metal objects for cleaning your appliance as it may get damaged.
-
Seite 4: Installation
Installation Caution If this appliance featuring magnetic door seals is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that spring lock unusable before you discard the old appliance. This will prevent it from becoming a death-trap for a child. Location Place the appliance away from all heat sources, such as: radiators, heating stoves, direct sunlight, etc. -
Seite 5: Operation
Operation Refrigerator/Freezer - Starting-up and Temperature Regulation Insert the plug into the wall socket. Open the refrigerator door and turn the thermostat knob, to be found on the upper right side of the inner liner, clockwise, beyond the «O» (STOP) position, to start the appliance. Temperature adjustment is obtained by turning the thermostat knob to the required set- ting. -
Seite 6: Zero Degree Compartment
Water ices, if consumed immediately after removal from the freezer compartment, can possibly cause the skin to be freeze burnt. Remember that, once thawed, frozen food deteriorates rapidly. Ambient switch With a room temperature lower than +14°C, switch (A) (see Fig. 1) should be depressed (the built-in light will come on). -
Seite 7: Storage Of Frozen Food
Fig. 1a D730 Food recommended for storage in the ZERO DEGREE compartment The following foods can be stored in this compartment: low humidity: MEAT MILK FISH BUTTER SHELLFISH SOFT CHEESES high humidity: MUSHROOMS STRAWBERRIES ARTICHOKES RASPBERRIES ASPARAGUS PEACHES CAULIFLOWER APRICOTS CARROTS APPLES PEARS... -
Seite 8: Fresh Food Refrigeration
Thawing Deep-frozen or frozen food, prior to being used, can be thawed in the refrigerator com- partment or at room temperature, depending on the time available for this operation. Small pieces may even be cooked still frozen, directly from the freezer: in this case, cook- ing will take longer. - Seite 9 Defrosting Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates. It is important to periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside.
-
Seite 10: Maintenance
leave the door open, place a basin on the top glass shelf of the refrigerator compartment, under the drain hole, remove the plug as shown in the figure; Fig. 4 PR151 when defrosting is completed, dry the interior thoroughly and refit the plug; keep the scraper for future use;... -
Seite 11: Interior Light
Interior light The light bulb inside the refrigerator compartment can be reached as follows: unscrew the light cover securing screws; unhook the moving part by pressing it as shown in the figure. If the door is open and the light does not come on, check that the bulb is properly screwed in;... - Seite 12 Instructions for fully built-in appliances Model Height of housing Depth of housing Width of housing AKE 8220 IW 1446 mm 550 mm 560 mm The appliance doors have been locked in position for transport by means of pins on both sides.
- Seite 13 Fig. 8 Open the door and push the appliance against the side of the kitchen furniture opposite to that of the appliance hinges. Fasten the appliance with 4 screws pro- vided in the kit included with the appliance. D570 Fig. 9 Press in the joint covers between the appli- ance and the kitchen furniture.
- Seite 14 Fig. 11 Position the runners (H) at the top and bot- tom of the inside of the kitchen unit as shown in Fig. 11 and mark the position of the external holes. After preparing the holes, screw the runners to the kitchen unit door using 3.5x16 mm screws.
- Seite 15 Inner door reversal Using a screwdriver release bracket (1) by pressing on the internal spring (Fig. 14) and withdraw it from its seat together with the door; remove plug (2) and fit it in the hole left open on the opposite side; turn the door through 180°, remove the bracket (1) and refit it on the opposite side.
- Seite 16 ® 2222 350-11 1 2 3 4 5 6 7 8 9 10 11 12 / 1997...
