INsTallaTIoN

oPeratIon: This faucet features an IP67 dual power input box. The product can
be operated with a 9V battery or a 9V transformer. In addition, when used with a
transformer, the product contains an integrated battery back up, for normal use during
power supply failures.
sTEP 1 – PREPaRaTIoN FoR mouNTINg ThE FaucET
1
shut off the water supply.
Remove the hexagonal nut, the disk
2
and the gasket. Do not remove the
O-ring from the base of the faucet.
sTEP 2 – INsTallINg ThE FaucET
Place the faucet with O-ring into the
hole in deck or lavatory. make sure
1
the O-ring is located between the
deck or lavatory and the bottom of the
faucet.
slide the gasket, disk and hexagonal
2
nut over the flexible hose and secure
the faucet into place.
4
O-Ring
gasket
disc
nut
O-Ring
O-Ring
O-Ring
gasket
disc
gasket
disc
nut
nut
INsTallaTIoN
Connect the flexible tube to the
solenoid valve body integrated in
the dual power input box.
Connect the water tube coming from
3
the faucet body to the nut at the
top of the dual power input box, by
snapping it in.
sTEP 4 – coNNEcTINg ThE PowER souRcE
Open the dual power box using the Allen key
provided and install the 9V Alkaline battery.
Connect the four contacts connector to the
dual power input box.
Important: make sure that the 4 contacts connector is connected all the way through.
tranSFormer VerSIon
Plug the transformer into the electricity socket
and connect the connectors.
sTEP 3 – coNNEcTINg ThE waTER suPPly
Connect the flexible pipe to the water
1
supply.
makE suRE ThaT ThE FIlTERs aRE INsTallED bETwEEN ThE FlEXIblE PIPE
aND ThE shuT oFF ValVE/aNglE ValVE (NoT suPPlIED).
Turn on the central water supply and
2
the shut-off valves (angle valves).
Check for leaks.
O-RINg VIsIBLE – NOT CONNECTED PROPERLY
ONLY ThE gROOVEs ARE VIsIBLE – CONNECTED PROPERLY
