IV. Power Supply Removal
1. Please first read Chapter II. Warning! Important Safety Information above.
2. Make sure that your system is entirely powered off; set the power supply's AC power switch to the "O" (OFF) position and disconnect the
power cord from the AC outlet.
3. Open the computer case (please refer to the manufacturer's user manual).
4. Carefully disconnect all the power supply's connectors from the mainboard and the peripherals.
5. Unscrew the mounting screws securing the power supply unit to the back panel of the case.
6. Carefully remove the power supply from the case.
V. Power Supply Installation
1. Place the Phanteks power supply into the space provided within the case and use the four mounting screws provided in the accessory bag to
secure it to the back panel of the case. Do not over-tighten the screws.
a. For power supplies with a built-in fan, the fan side top cover should be facing the mainboard. (Depending on the type of computer case, this
can mean either upwards or downwards facing fan cover.)
b. For fanless power supplies, Phanteks recommends to mount fanless power supplies into the computer case with their ventilation cover facing
UPWARDS. However, there are extra mounting-screw holes provided on the back of the power supply to allow for reverse mounting, if
necessary.
2. Mainboard connection:
a. DO NOT force the connectors into place; the connectors are "keyed" so they can only fit one way. Make sure that the connectors lock in their
place securely.
b. Connect the power supply end of the 24/20-Pin convertible connector to the appropriate receptor on the power supply unit.
c. Connect the mainboard end of the 24/20-Pin convertible connector to the mainboard. Depending on the mainboard, you may need to either
attach or detach the 4-Pin module of the 24/20-Pin connector.
d. Connect the + 12 V 4-Pin connector and the EPS + 12 V connector, if applicable.
e. If your system requires dual EPS + 12 V connectors, please connect the 8-Pin end of the second CPU 8-Pin connector into the appropriate
8-Pin receptor on the power supply unit. Then connect the mainboard end of this 8-Pin connector to the mainboard.
3. Peripheral components connection
a. Connect one end of the peripheral cable to the power supply and the other end to the component.
