XI. DC Power Connectors
24 / 20 Pin Main Power Connector
24 12
23 11
22 10
21 9
20 8
19 7
18 6
17 5
16 4
15 3
14 2
13 1
Pin13 Pin1
8 / 4 Pin +12V Power Connector
8 4
7 3
6 2
5 1
Pin5 Pin1
8 Pin +12V Power Connector
8 4
P2
7 3
6 2
5 1
Pin5 Pin1
8 / 6 Pin PCI Express Connector
8 4
7 3
6 2
5 1
Pin5 Pin1
Black
COM 24 12 Black +3.3VDC
+5VDC Black 23 11 Black +12VDC
+5VDC Black 22 10 Black +12VDC
+5VDC Black 21 9 Black +5VSB
NC NC 20 8 Black PWR_OK
COM Black 19 7 Black COM
COM Black 18 6 Black +5VDC
COM Black 17 5 Black COM
PS_ON# Black 16 4 Black +5VDC
COM Black 15 3 Black COM
-12VDC Black 14 2 Black +3.3VDC
+3.3VDC Black 13 1 Black +3.3VDC
+12VDC Black 8 4 Black COM
+12VDC Black 7 3 Black COM
+12VDC Black 6 2 Black COM
+12VDC Black 5 1 Black COM
+12VDC Black 8 4 Black COM
+12VDC Black 7 3 Black COM
+12VDC Black 6 2 Black COM
+12VDC Black 5 1 Black COM
COM Black 8 4 Black COM
COM Black 7 3 Black +12VDC
COM Black 6 2 Black +12VDC
COM Black 5 1 Black +12VDC
Serial ATA Connector
Pin1
Peripheral Power Connector
Pin1
Pin4
ATTENTION! Please make sure that the connector is plugged in tightly AND all
metal pins are matched up correctly in the plastic housing.
53
1 1 +3.3VDC
2 2 +3.3VDC
Black
3 3 +3.3VDC
4 4 COM
5 5 Black COM
6 6 COM
7 7 +5VDC
8 8 Black +5VDC
9 9 +5VDC
10 10 COM
11 11 Black COM
12 12 COM
13 13 +12VDC
14 14 Black +12VDC
15 15 +12VDC
1
1 Black +12VDC
2
2 Black COM
3 Black COM
3
4 Black +5VDC
4
