Items Not Provided
•
•
Installing the Vehicle Mount
1 Use the four hex screws and the hex key to attach the RAM
2 Use the four 1/4-inch-flathead hex screws and nuts to attach
3 Place the mounting arm over the two bases, and then tighten
4
Common hand tools.
Electric drill and drill bits.
vehicle mount base to the vehicle mount.
the RAM vehicle base to your vehicle.
the mounting arm.
RAM vehicle
mount base
Vehicle
mount
Hex screw
(4 places)
Vehicle
mount
Mounting arm
RAM vehicle
mount base
RAM
vehicle base
