General Description

The PG27-USB large diaphragm side-address condenser microphone features a neutral frequency
response and low-self noise for faithful reproduction of a wide variety of sound sources—from piano
and wind instruments to drum overheads, acoustic guitars, and vocals.
Mic Gain
A
Microphone Capsule: 1.1-inch (27 mm) gold-sputtered Mylar
B
Pad Switch: Use to prevent clipping from extremely loud sound sources.
C
MIC GAIN: Adjusts microphone input level before the analog to digital conversion.
D Tri-color peak level indicator: Green = signal, Yellow = peak, Red = clipping
E USB Connector: Digital audio input and output
F USB Power Indicator: Illuminates green when properly connected to a powered computer USB port.
G Headphone jack: For zero-latency direct monitoring.
H VOLUME: Adjusts headphone volume
I MONITOR: Blends pre-recorded playback from the computer with live audio from the microphone.
8
Volume
diaphragm
®
