MPR 210 – Condenser Microphone
12
6.

Maintenance

Use a soft, damp cloth for cleaning the MPR 210 microphone. If
necessary, you can use a gentle cleansing agent (such as washing-
up liquid). Make sure not to allow any water to enter the transducer
element and never use any solvent cleansers.
7.

Service

Servicing must be carried out by qualified service personnel only.
Dismantling the microphone yourself will invalidate the guarantee.
8.

Version

MPR 210 B Desktop microphone with Revoluto
Microphone Array technology,
corridor characteristic, black . . . . Order # 725.145
MPR 210 W same as above, but white . . . . . . Order # 725.080
9.

Technical Specifications

Transducer type . . . . . . . . . . . . . . . . . . . Condenser
Frequency response . . . . . . . . . . . . . . . . 130 - 17,000 Hz
Microphone . . . . . . . . . . . . . . . . . . . . . . Microphone Array,
Polar pattern . . . . . . . . . . . . . . . . . . . . . Corridor
Optimal distance when speaking . . . . . . . 60 - 80 cm
Open circuit voltage at 1 kHz. . . . . . . . . . approx. 200 mV/Pa
Output level depending on the
selected position
Hi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 mV/Pa
Mid . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 mV/Pa (-10 dB)
Lo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 mV/Pa (-20 dB)
Nominal impedance . . . . . . . . . . . . . . . . 200 Ω
Load impedance . . . . . . . . . . . . . . . . . . . > 1 kΩ
Max. SPL at f = 1 kHz, k < 1% . . . . . . . . 112 dB
Signal-to-noise ratio rel. to 1 Pa. . . . . . . . 60 dB
Voltage supply . . . . . . . . . . . . . . . . . . . . Phantom powering
Power consumption . . . . . . . . . . . . . . . . 8 mA
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.1%
Connection . . . . . . . . . . . . . . . . . . . . . . 3-pin XLR, male
Temperature range . . . . . . . . . . . . . . . . . -10 °C to +40 °C
Dimensions (L x H x D) . . . . . . . . . . . . . . 300 x 40 x 45.5 mm
Weight (without cable) . . . . . . . . . . . . . . 230 g
(back electret)
patented
48 V ±4 V to 6.8 kΩ
supply impedance
24 V ±4 V to 1.2 kΩ
supply impedance
MPR 210 – Condenser Microphone

10. Wiring Diagram
