USING THE HOOD
1. Control panel.
2. Grease filter (above the perimeter suction filter).
3. Halogen bulbs.
4. Telescopic chimney.
5. Perimeter suction panel.
Control panel
a. ON/OFF light key
b. Motor ON/OFF key and minimum speed selection (suction power).
c. Medium speed selection key (power and suction)
d. Maximum speed selection key (power and suction)
MAINTENANCE
WARNING:
Cleaning the perimeter suction panel
Dismantling:
Pull the panel (FRONT SIDE) downwards
Cleaning:
The suction panel must be cleaned with the same frequency as the grease filter. Use a damp
cloth and a soft liquid detergent.
Do not use products containing abrasives.
WARNING: DO NOT USE ALCOHOL!
Assembly:
The panel must be fixed from the front, hinged to the appropriate pins on the surface of the
hood.
WARNING: Always check that the panel is fitted properly.
- Disconnect the appliance from the power supply.
a
GB16
b c d
