GB
A 21mm G½ (½"bsp) Adaptor
B 26.5mm G¾ (¾"bsp) Adaptor
C 33.3mm G1 (1"bsp) Adaptor
D Duration dial
E LED indicator lights
F Water Now button - On/Off/Override
G Hose pipe connector
H Light Sensor
Installation & operating instructions
READ THESE INSTRUCTIONS CAREFULLY BEFORE
ATTEMPTING TO USE THIS PRODUCT.
FAILURE TO OBSERVE THE FOLLOWING NOTICES MAY RESULT
IN INJURY OR PRODUCT DAMAGE

General information

THESE INSTRUCTIONS ARE ALSO AVAILABLE ON THE
HOZELOCK WEBSITE.
This product meets the requirements of IP44 and therefore can
be used in exposed weather conditions.
This product is not suitable for supplying drinking water.
Threaded water connections are suitable for hand tightening
4
only.
This product can be fitted to mains water supply.
This product can be fitted to outdoor water butts or tanks that
have an inline filter fitted before the controller.
Installing the batteries
You must use Alkaline batteries – alternatives will result in
incorrect operation.
Remove the front panel as shown (Fig. 1), gripping the recessed
1
part and pulling towards you.
Insert 2 x 1.5v AA (LR6) batteries (Fig. 1) and replace the
2
controller front panel.
IMPORTANT: Rechargeable batteries must not be used.
3 Replace batteries each season. (max 8 months use, used twice a
day)
4 When batteries are installed the motor will operate the internal
valve to check that it is ready for use and the batteries installed
have enough charge to safely operate the valve
5 If the LED indicator flashes red, the batteries need to be
replaced.
Connecting the Sensor Controller to the tap
Choose the correct tap adapter (Fig. 3)
1
Using the correct adapter(s), attach the controller to the tap and
2
tighten firmly to avoid leaks. Do not use a spanner or other tool
to tighten as this might damage the threads. (Fig. 4)
3 Turn on the Tap.
How to set up the Sensor Controller - automatic
watering
Sunrise and Sunset is the best time to water your garden to avoid
evaporation and leaf scorch. The Daylight sensor automatically
adjusts the watering schedule to coincide with the changing time
for sunrise and sunset.
Cloudy or overcast mornings and evenings might cause a slight
delay to the watering times, but these are not significant to have
any adverse effects on your garden.
1 Rotate the control dial to select from the 3 marked sections –
Sunrise (once a day), Sunset (once a day) or Sunrise and Sunset
(twice a day). (See Fig. 5)
Choose from the required watering durations – 2, 5, 10, 20, 30 or
2
60 minutes of watering.
How to turn off the Sensor Controller
If you do not want the controller to automatically come on turn the
rotary dial to the "OFF" position. You can still use the button to
manually water your garden.
Initial synchronisation period
When you install new batteries there is a 6 hour lockout period to
prevent the controller from watering while you are setting up your
system. After a 24 hour cycle of Sunrise and Sunset the controller
will be synchronised with the changing light levels. You can
manually water your garden using the button during the 6 hour
lockout period.
Positioning your Sensor Controller outdoors
It is important that your water controller is in an outdoor location.
Do not point the control panel directly towards outdoor security
lights or other bright lights that come on during the night as
these might interfere with the recorded light levels and cause the
controller to come on at the wrong time.
Ideally, you should not set up your controller in a heavily shaded
passageway or behind buildings where light levels remain low
all day long. Do not position the controller inside buildings such
as garages or sheds where it will not receive natural daylight to
function correctly.
The controller is designed to be positioned directly underneath an
outdoor tap. Do not position the controller on its side or lying on the
ground whereby rainwater cannot flow away from the product.
1 hour delay
(when using 2 Sensor Controllers together)
If you install two Sensor Controllers you might want to stagger the
start times to prevent pressure loss when two appliances are used
simultaneously – for example sprinklers.
Remove the delay plug from the storage location on the back of
the control panel (Fig. 2) and fit the plug on the location below the
batteries.
With the plug inserted the one hour delay affects all automatic
watering. The delay period of one hour cannot be changed.
Manual operation (water now)
You can turn on the water controller at any time by pressing the
button once. Press again to turn off at any time.
5
