WARNING: Make sure to follow these
instructions for use. Incorrect use and/or
not following the instructions can lead to
dangerous situations causing severe injuries
to humans and/or serious damage to pro-
perty.
• Warning: Do not interfere with any of the
sealed components.

ASSEMBLING THE APPLIANCE

Before connecting the low-pressure regulator, please follow the instructions
provided with the low-pressure regulator.
The manufacturer is not responsible for any harm or damage if attention is not
paid to the points described above. Do not twist the flexible tubing or the hose.
Gas hose to be minimal 80 cm and max 160 cm. Internal diameter between 8 and
12 mm. Make sure that the gas hose applies with local legislation and standards.
INSTALLATION REQUIREMENTS
• The flame-check window of the water heater shall be at eye level of the user.
• Make sure all electrical lines or electric equipment is at least 400mm away from
the appliance in all directions.
• Clearance distances: see fig. 2 and fig. 3.
• The product must be positioned vertical with the gas- and water connections
mounted perfectly downwards.
• Make sure the product is fixated thoroughly so it cannot fall.
INSTALLATION METHOD:
Carefully remove your appliance from the box and check the contents for any
damage. Mount the product as shown in fig 6.

DIRECTIONS FOR USE

If you have any doubts concerning the heater, please contact qualified service
personnel. Keep all packaging material out of the reach of young children. Before
connecting the low-pressure regulator, please check and read the following:
The appliance should only be powered by propane-butane in a container with
a maximum weight of 15 kg. Connect the low-pressure regulator with a fixed
calibration of maximum 30 mbar that complies with EN 12864:2002. The hose
should be according to national standards. For correct connection, follow the
instructions provided with the low pressure regulator.
• Connect the regulator to the gas container.
• Connect the correct end of the gas hose to the regulator (see fig. 4).
• Connect the other end of the gas hose to the appliance (see fig 4). Use the 3
4
53
