WARNING! The external input does not have an automatic volume limit. You
must limit the volume on the external equipment manually.

MAINTENANCE

Clean the outside of the headset regularly with soap and warm water.
Note: Do not immerse in fluids. After long hours of use, or other situations in which
the Lite-Com Basic is exposed to moisture inside, the hygiene set should removed
so the hearing protector can dry before the next use. Do not store the headset in
temperatures exceeding +55°C, for example in a windscreen or window. The headset
(especially the ear cushions) can wear out over time. Inspect them often and regularly
to ensure that there are no cracks or sound leakage. Certain chemical substances
may be harmful to this product. Contact Peltor for more information.
When the Lite-Com Basic indicates low battery power (3 tones every 30 seconds),
it's time to replace the batteries. After 5 minutes the Lite-Com Basic switches off
automatically.
Never replace or install batteries with the unit switched on. Before switching on,
make sure that the batteries are inserted correctly.
Always wear, adjust, clean and maintain the headset according to these
instructions. If these recommendations are not followed, attenuation and other
functions can be impaired.
CE
The Peltor Lite-Com Basic is tested and approved as a hearing protector according
to PPE directive 89/686 EEC and applicable parts of the European EN 352-1 and
EN 352-3 standards. Certified by FIOH, Topeliuksenkatu 41a, FIN-00250 Helsinki,
Finland, ID# 0403. Measurements for products with a helmet attachment were
performed on Peltor's G22C hardhat.
The Lite-Com Basic is also tested and approved according to the following standards:
Radio: ETSI EN 300 296-2, ETSI EN 300 296-1
EMC: ETSI EN 301 489-5, ETSI EN 301 489-1
The electrical measurements were performed by SP, the Swedish National Testing
and Research Institute, Box 857, SE-501 15 Borås, Sweden, ID# 0402.

TECHNICAL DATA

Frequency:
Channels:
Channel steps:
Deviation:
Output:
Range:
Traffic method:
Power consumption:
Operating temperature:
Storage temperature:
Weight including batteries:
ATTENUATION VALUES (Fig. E)
1. Frequency
2. Average value
3. Standard deviation
4. Average protection value
PELTOR Lite-Com Basic MODELS
MT53H7A4400 with headband
MT53H7P3E4400 with helmet attachment for PELTOR G22 and G3000 hardhats
(a rear plate is also included for helmet attachments for the PELTOR G2000 hard-
hat).

SPARE PARTS AND ACCESSORIES

Hygiene kit HY79
Easy to replace hygiene kit consisting of two attenuation cushions, two foam rings
and snap-in ear cushions. Replace at least twice a year to ensure constant attenu-
ation, hygiene and comfort.
Clean single-use protectors HY100A
A single-use protector that is easy to apply to the ear cushions. Packages of 100
pairs.
Mike Protector HYM1000
Moisture and wind-tight and hygienic; protects the speech microphone and enhances
its life span. Packages of 5 metres, about 50 replacements.
20
446.00625-446.09375 MHz
8
12.5 kHz
Max. ± 2.5 kHz
150/25 mW ERP
Outdoors up to 2000 metres depending
on conditions
Simplex
Stand-by and receiving, 60–70 mA
Transmitting, approx. 110 mA (LO), 200 mA (HI)
-20°C to +55°C
-40°C to +55°C
MT53H7A4400 390 g
MT53H7P3E4400 410 g
