Jigsaw
Art.no 18-3557 Model JD2902LK-UK
40-8774 JD2902LK
Please read the entire instruction manual before using the product and then save
it for future reference. We reserve the right for any errors in text or images and any
necessary changes made to technical data. In the event of technical problems or other
queries, please contact our customer services (see address details on the back).
Contents
1. Safety .................................................................................4
1.1 General Safety Requirements - EN 60745-1 .......................................... 4
1.2 Safety Instructions - Jigsaw EN 60745-2-11 .......................................... 6
1.3 Product safety symbols ........................................................................ 6
2. Product description ............................................................ 7
3. Assembly and setup ...........................................................8
3.1 Changing the blade .............................................................................. 8
3.2 Fitting the edge guide .......................................................................... 8
3.3 Adjusting the soleplate bevel angle ..................................................... 9
3.4 Setting the pendulum action ................................................................ 9
3.5 Laser/LED light ................................................................................... 10
3.6 Setting the blade speed ...................................................................... 10
3.7 Switch operation ................................................................................. 10
3.8 Vacuum cleaner dust extraction .......................................................... 11
4. Operating tips ...................................................................11
4.1 Preparations ........................................................................................ 11
4.2 Sawing ................................................................................................ 11
4.3 Internal cuts ........................................................................................ 11
4.4 Sawing metal ...................................................................................... 12
5. Troubleshooting ............................................................... 12
6. Care and maintenance ..................................................... 13
7. Disposal ........................................................................... 13
8. Specifications .................................................................. 13
3
