3.5 Laser/LED light

The laser/LED light is controlled by a switch
(7) on the front of the housing. The laser
projects a line in front of the jigsaw to help
guide the sawing line.
Press the switch the required number of
times to select one of the following settings:
LED worklight
ON
OFF
ON
OFF
Warning:
Never point the laser beam at a person or animal. Never look directly into the laser
beam. The laser beam can cause permanent eye damage.

3.6 Setting the blade speed

The blade speed can be adjusted to suit
the material by rotating the speed selector
control (8), even during operation. 1 = lowest
speed, 6 = highest speed.
After cutting for an extended time at low
speed the motor should be run at maximum
speed for about 3 minutes to cool down
the motor.

3.7 Switch operation

Starting the jigsaw: To start the jigsaw, pull
and hold in the trigger (9).
Stopping the jigsaw: Release the trigger to
stop the jigsaw.
The jigsaw is equipped with a lock button (10) to lock the trigger on for longer cuts.
To lock the trigger (9) in the on position:
Press the lock button (10) and trigger (9) simultaneously and then release the trigger
before the lock button.
Stopping when the trigger is locked:
To disengage the trigger lock and stop the jigsaw, pull and release the trigger (9) once.
Laser
OFF
ON
ON
OFF
10
7
5
8
10
9
