2.1 Cable connection

A B 24V
LON
LON bus connection
and 24 VAC/VDC
supply voltage
Continuation of
LON bus connection
and 24 VAC/VDC
supply voltage
Note: The cables must not cover the LED.
G10
Pump
An example of cable connection can be found on page 47.
A Y B
GENIbus
LED PIN
SERVICE
To Grundfos pump
LON network
24 VAC/VDC
G10 G10
Pump Pump
