IMPOrTaNT FeaTUreS

Micro helicopter:
• New coaxial rotor system with
electronic gyro for outstanding flying
properties
• Sturdy plastic hull with LED lighting
Safety instructions:
• This helicopter is suitable for pilots
who are at least 8 years of age.
Adult supervision is required
when flying it.
• Warning! Not suitable for children under
36 months. Small parts. Choking hazard!
• This helicopter is suitable for use
indoors areas.
• Keep your hands, face and loose clothing
away from the helicopter.
• Switch off the remote control and
helicopter when they are not in use.
• Remove the batteries from the remote control
when it is not in use.
• Always maintain visual contact with the
helicopter in order to avoid losing control
of it. Inattentive and careless use can
lead to considerable damage.
• Please keep this operating manual safe
for later use.
• The user should only operate this heli copter
in accordance with the in structions for use
in this operating manual.
• Do not fly the helicopter near people,
animals, bodies of water or power lines.
• This helicopter is not suitable for people
with physical or mental disabilities.
We recommend that people who are
un familiar with model helicopters operate
the model under the guidance of an
experienced pilot.
• In general, it must be ensured that the
model cannot injure anyone in considera-
tion of potential malfunctions and defects.
• The product may only be repaired or
modified with approved original parts.
12
• Integrated rechargeable LiPo battery
(Lithium Polymer battery)
• Simple charging of the battery directly
through the charger built into the
remote control – with microprocessor-
monitored charging control
Otherwise, the helicopter can be be
damaged or pose a danger.
• In order to prevent risks, always operate the
helicopter from a position which provides an
easy line of retreat, if necessary.
Remote control safety instructions:
• Rechargeable batteries must be removed
from the remote control prior to recharging.
• Non-rechargeable batteries may not be
charged.
• Rechargeable batteries may only be
charged under the supervision of an adult.
• The combination of different types of
batteries as well as new and used
batteries must be avoided.
• Only recommended batteries or those of
an equivalent type may be used.
• We recommend new alkali manganese
batteries for the remote control. Single-
use batteries for this remote control and
other electrical devices operated in the
home can be replaced with environmen-
tally-friendly rechargeable batteries.
• Batteries must be inserted according to
the correct polarity (+ and -).
• Depleted batteries must be removed from
the remote control.
• The connection terminals may not be
short-circuited. Please remove the
batteries from the remote control if it is
not to be used for an extended period of
time.
• As soon as the remote control no longer
functions reliably, new batteries should be
inserted and/or the batteries should be
charged.
Charging unit safety instructions:
1. Non-rechargeable batteries may
not be charged.
2. This charging unit is not suitable for
people (including children) with
physical or mental limitations, or
those with insufficient knowledge
and experience of charging units,
unless under supervision or
following proper directions from
a parent or legal guardian.
3. Children must be supervised –
the charging unit is not a toy!
4. The charging unit for the LiPo
battery is specially designed for the
charging of the helicopter battery.
The charging unit may only be used
to charge the helicopter battery, not
other batteries.
The helicopter is equipped with
a rechargeable lithiumpolymer
battery. Please observe the
following safety instructions:
• Never throw LiPo batteries into a fire
or store them in a hot location.
• Only use the supplied charger to
charge the battery. The use of a
different charger may lead to the
permanent damage of the battery
and neighbouring parts, as well as
physical injury!
• Never use a charger for
NiCd/NiMH batteries!
• Always ensure that the charging
process takes place on a fireproof
surface in a fire-resistant environment.
• Do not leave the battery unsupervised
during the charging process.
• Never disassemble or alter
the battery contacts. Do not damage
or puncture the battery cells. There is
a risk of explosion!
• The LiPo battery must be kept out of
reach of children.
• When disposing of batteries, they
must be discharged or their capacity
must be fully depleted. Cover exposed
terminals with adhesive tape in order
to prevent short-circuiting!
Maintenance and care:
• Please only use a clean, damp cloth
to wipe off the helicopter
• Protect the helicopter and batteries
from direct sunlight and/or direct heat.
• Never allow the helicopter to come
into contact with water. This may result
in its electronics becoming damaged.
• Transformers, mains adapters or
chargers which are used together
with the model must be checked
regularly for damage to cables,
plugs, housings and other parts and
any damages must be repaired
before the devices may be used again.
Required batteries for the
helicopter:
Power supply: ===
Rated output: DC 3.7 V, 0.52 Wh
Batteries: 1 x 3.7 V rechargeable
LiPo battery (built in)
Capacity: 80 mAh
USB charger:
Power supply: ===
Rated output: 5 V / 500 mA
Battery requirement for the
remote control:
Power supply: ===
DC 9 V
Batteries: 6 x 1.5 V "AA"
(not supplied)
1 helICOPTer
1A Stabiliser 1D Landing gear
1B Counter-rotating 1E Tail rotor
rotor blades
1F ON/OFF switch
1C LED lighting
1G Charge socket
