JETIBOX is a universal communication terminal, which can be used with any
JETI products that are marked JETIBOX Compatible (JBC). JETIBOX
Compatible products use powerful software to allow easy setup and reading
of data using a simple menu driven display on the JETIBOX terminal.
Application JETIBOX:
1. Measurement of receiver channel outputs pulse widths
2. Servo pulse generator
3. Servo cycler
4. Measurement of servo transfer speeds
5. Communication with controllers SPIN (see controller SPIN operating instructions)
6. Communication with sensor controllers for BLDC
7. Communication with REX JBC receivers
8. Communication with SYSTEM DUPLEX
For application #1 you need a receiver, transmitter and receiver batteries (4,8-8,4V). Plug
batteries into socket GRAY, receiver to socket BLUE, both on the right side of the JETI BOX.
For applications #2, #3 and #4 you need the receiver batteries (4,8-8,4V) and a servo. Connect
the batteries to socket first GRAY and the servo to socket BLUE.
In case of change of the application you must disconnect the supply battery from the JETI BOX
and activate them again. In order to choose the required application use the push-buttons
R and L.
If you do not have RX batteries or another kind of voltage source (range of 4,8-8,4V) you can
supply the JETI BOX from the BEC of the controller (do not for SPIN OPTO). Plug the JR
connector of the controller into socket GRAY (pulse (orange cable) into the unmarked position).
Connect the flight batteries to the controller an switch on the switch (if available).
Products marked "JETIBOX COMPATIBLE"
5
communicate with JETIBOX
