PARTS OVERVIEW

A
Main body
B
Ab-support pad
C
Left handle bar with magnetic sensor
D
Right handle bar
E
Rear ground tube
F
Manual
G
Computer
H
Knob head locking shaft
I
2 x AA alkaline battery
J
Locking pin
K
Carriage bolt M8x70mm (for assembly of part 13 x 2 Pcs)
L
Hex head bolt M8x80mm (for assembly of part 14 x 2 Pcs)
M
Tools
N
Knob head screw M8x53mm (for assembly of part 36 x 1 Pc)
O
Knob head screw M8x70mm (for assembly of part 38 x 2 Pcs)
P
Knob head screw M8x15mm (for assembly of part 37 x 1 Pc)
