Divus CIRCLE Schnellstartanleitung Seite 5

A
DATASHEET
1
Power supply
12-50 VDC
12-35 VAC
12 /24 VDC
1,5 A max total
GND
12
A. Power supply (reversable)
B. 4 digital inputs
C. Rotary switch for modbus address
D.
RS-485 - FTP AWG20/24 cable (Connect the cable shield to GND pin)
E. 2 Programmable outputs 12/24 VDC (max. 1.5 A total) on both ports
F. 2 Relay outputs to connect light, FCU, roller shutter motors, any other controlled load
B
2
3 4 5 6
COM IN1 IN2 IN3 IN4
Digital Inputs
Output
1 GND 2
13 14 15
E
C
7 8
1
COM
Address
Switch
Relay outputs -
Max resistive load 6A
RL1
16 17
Quick Start Guide
OPTIONAL I/O MODULE
D
9 10 11
B A
GND
Term.
RS485
R
RL2
18 19
F
EN
5
