Parts List Pneumatic

ID
1V1
1V2
1V3
1B1
0V1
2V3
1S1
The repair of the machine has to be executed by trained personnel. Please contact the
producer or distributor of the machine!
Service address:
WEZAG GmbH
Werkzeugfabrik
Wittigstraße 8
35260 Stadtallendorf
Telephone: +49 6428 704-0
14.5

Accessories overview for re orders

1. Pneumatic foot pedal with cover
2. Air hose set
3. Hexagon wrench key set
4. Grease gun
5. T-handle
6. Power supply with changeable adapters
UP35-4481N26000-02/15 – REV.B1
Pieces Article Number
1 8480-88086
1 8480-85002
1 8480-88089
1 8480-88005
1 8481-03003
1 8480-88073
8481-03042 +
1
8481-03018
Description
Oder valve
5/2 pneumatic valve
5/3 pneumatic valve
Button (1A1 extended)
Pressure control valve, adjustable
Throttle valve
Palm switch red incl. Valve
order no.: 1481-03033
order no.: 1881-03001
order no.: 1881-02002
order no.: 9480-88019
order no.: 8481-02005
order no.: 1881-03005
