Installation Instructions - CHIEF RPE Montageanleitung

Installation Instructions

LEGEND
TOOLS REQUIRED FOR INSTALLATION / PARTS
7/16"
1/8" (wood)
7/16"
M6
(included)
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Phillips Screwdriver
Destornillador Phillips
Kreuzschlitzschraubendreher
Chave de fendas Phillips
Cacciavite a stella
Kruiskopschroevendraaier
Tournevis à pointe cruciforme
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clé à fourche
Hardware required - not included
(dependent on installation method)
1. Install to threaded extension column
• 1-1/2" NPT or NPSM steel or aluminum
threaded extension column rated for 50 lbs
or greater
2. Install to wood ceiling joists
• 1/4" x 2" (minimum length) lag bolts (Qty. 4)
• 1/4" steel washers (Qty. 4)
3. Install to threaded rod
• 1/4-20 steel threaded rods (Qty. 4)
• 1/4-20 steel channel nuts (Qty. 4)
• 1/4-20 steel jam nuts (Qty. 8)
• 1/4" steel washers (Qty. 8)
Adjust
Ajustar
Einstellen
Ajustar
Regolare
Afstellen
Ajuster
Security Wrench
Llave de seguridad
Sicherheitsschlüssel
Chave de segurança
Chiave di sicurezza
Veiligheidssleutel
Clé de sécurité
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clé à tête hexagonale
Socket Wrench
Clé à douilles
Steckschlüssel
Chave de caixa
Chiave a brugola
Dopsleutel
Clé à douilles
A (1)
[RPE]
B (1)
[Example of SLB bracket]
C (4)
M6X16mm
M6x16mm (security)
F (2)
E (2)
M6
M6
RPE
D (4)
G (1)
M6
