AEC-PANEL19-UPS
Rack mounting for AMC2, PBC-60 and rechargeable Batteries
Figure 1 Mounting plate for two AMC devices plus power supply
X = Front view; Y = Rear view
1.
2.
3.
4.
5.
6.
7.
F.01U.097.256 | V 1.1 | 2008.12
Power supply connections (pre mounted)
Screw sockets (pre mounted) for holding the PBC-60
power supply
Battery bracket
Cable channels
Grounding connection (pre mounted)
DIN Rails (pre mounted)
Cut-outs for fixing the mounting plate in 19'' enclosures
