4.

General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
Keep this device away from dust and extreme temperatures. Make sure the ventilation openings
are clear at all times. For sufficient air circulation, leave at least 1" (± 2.5 cm) in front of the
openings.
Protect this device from shocks and abuse. Avoid brute force when operating the device.
 Familiarise yourself with the functions of the device before actually using it. Do not allow operation by
unqualified people. Any damage that may occur will most probably be due to unprofessional use of the
device.
 All modifications of the device are forbidden for safety reasons. Damage caused by user modifications to
the device is not covered by the warranty.
 Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks,
lamp explosion, crash, etc. Using the device in an unauthorised way will void the warranty.
 Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the
dealer will not accept responsibility for any ensuing defects or problems.
 Mechanical wear and LEDs are not covered by warranty.
 A qualified technician shall install and service this device.
 Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the
device against damage by leaving it switched off until it has reached room temperature.
 Use the appropriate current and power supply (see Technical Specifications).
 Lighting effects are not designed for permanent operation: regular operation breaks will prolong their lives.
 There may be a particular smell when the device is activated for the first time. This is normal and any smell
will gradually disappear.
Keep this manual for future reference.
5. Features
 full wash lighting solution for mobile entertainers
 set up and take down in no time using the included stand, foot switch, and carry bags
 several setup possibilities and configurations with 2 included L-brackets
 multiple control options with the included foot switch or standalone
 DMX control: 3 channel mode: RGB
15 channel mode: auto programs, dimmer, shutter, RGB for each PAR
 flicker-free operation
6. Overview
Refer to the illustrations on page 2 of this manual.
1 bracket (x 2), included
2 adjustment knob (pan)
3 fuse holder
4 DMX in
5 DMX out
6 footswitch connector
7 microphone sensitivity knob
7.

Mounting the Device

Safety
 Before mounting the product, read and follow the safety recommendations indicated in the Safety
Instructions.
Orientation
 Before deciding on a location, make sure there is easy access to the product for maintenance and
programming.
V. 03 – 08/07/2014
VDPLDJBAR7
8 display
9 power output to other fixtures (2)
10 menu buttons
11 microphone
12 stand connection
13 power in
14 adjustment knob (tilt)
