Description of the monitor Fig. 1
1. Brightness control
„
To increase the value, turn clockwise
2. Colour intensity adjustment for Art. 6701
Contrast adjustment for B/W monitor Art. 6700W
„
To increase the value, turn clockwise
3. 4.3'' LCD screen (in colour for Art. 6701, B/W for Art. 6700W)
4. Call volume adjustment (high - medium - low)
5. Monitor handset (lift handset to start communication)
Capsense key description:
„
Press the desired key once to activate the function associated with it.
Wait for approximately 1 sec. before pressing the same key again.
Pressing the same key several times in quick succession will cancel the
command.
Lock-release key: can be used to open the electronic door lock.
Key 1 Actuator function (programmable*): can be used to activate the relay
for a specific actuator installed within the system
Key 2 Self-ignition function (programmable*): can be used to receive images
from external unit cameras or from remote cameras.
Privacy key: can be used to exclude the ringtone on receipt of a call.
Keys (programmable*) present as standard on all black monitors (for
white monitors they can be added using an accessory*)
Indicator LED description:
Lock-release LED
slow flashing: door open
1 flash after pressing: door opening confirmation
continuous flashing: call in progress
Privacy LED
steady: privacy function enabled
3 flashes (every 5 sec.): doctor function enabled
4 flashes: system engaged
*For further information please contact your installer.
