Cleaning And Maintenance; Technical Specifications - HQ Power VDPL601MHB14 Bedienungsanleitung

Value
Channel
from
10 0
11 0
12 0
13 0
0
8
16
24
32
40
48
56
64
72
14* 80
88
96
104
112
120
128
136
144
152
160
* only when in non-rotating colour and gobo mode
7.

Cleaning and maintenance

 All screws should be tightened and free of corrosion.
 The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections...
 Mechanically moving parts must not show any signs of wear and tear.
 The electric power supply cables must not show any damage. Have a qualified technician maintain the
device.
 Disconnect the device from the mains prior to maintenance activities.
 Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
 There are no user-serviceable parts, apart from the fuse.
 Contact your dealer for spare parts if necessary.
8.

Technical specifications

power supply
LED
gobo size
power consumption
dimensions
weight
fuse
V. 03 – 29/09/2014
VDPL601MHx14
Function
to
255 pan position - fine
255 tilt position - fine
255 pan-tilt speed, slow -> fast
255 pan-tilt macro, fast -> slow
7 no function
15 pan-tilt move 3 seconds blackout
23 cancel pan-tilt move 3 seconds blackout
31 Colour wheel move while blackout
39 cancel colour wheel move while blackout
47 Gobo wheel move while blackout
55 cancel gobo wheel move while blackout
63 Gobo wheel rotate while blackout
71 cancel gobo wheel rotate while blackout
79 Prism move while blackout
87 cancel prism move while blackout
95 cancel all moving
103 pan reset
111 tilt reset
119 Colour wheel reset
127 Gobo wheel reset
135 Gobo rotating reset
143 Prism reset
151 Focus reset
159 Total reset
255 no function
VDPL601MHB14
278 x 278 x 490mm
(10.95" x 10.95" x 19.29")
14kg (30.86lb)
230Vac / 50Hz
Luminus (USA) high power
24.9mm (1")
90W
(10.83" x 10.95" x 13.19")
2A / 230VAC (FF2N)
10
VDPL601MHS14
275 x 278 x 335mm
12kg (26.46lb)
©Velleman nv
