Inhaltszusammenfassung für Eaton Ellipse MAX 600

  • Seite 1 w w w . e a t o n . c o m Ellipse MAX 600/850/1100/1500 Installation and user manual English - Français Deutsch - Italiano Español - Nederlands Português - Polski - Česky Solvenčina - Slovensko Magyar - Türkçe Pulsar Series...
  • Seite 2 Packaging Product should put on right direction as show above Ellipse MAX Ellipse MAX Ellipse MAX MAU-00033 AE...
  • Seite 3: Quick Start

    Quick start IEC / UNIVERSAL FR / DIN Ellipse Max 850/1100 / Ellipse Max 600 1500 USBS Ellipse Max 600 USBS MAU-00033 AE...
  • Seite 4: Battery Change

    Quick start Ellipse MAX 600 / 850 / 1100 / 1500 USBS ���� ������������ ��� Product representations not legally binding. Battery change The battery elements must be replaced exclusively by qualified personnel (risk of electrocution) Les éléments batterie ne peuvent être remplacés que par du personnel qualifié (risque d’électrocution)
  • Seite 5: Technical Characteristics

    Technical characteristics 1500 Ellipse MAX: 1100 UPS power 850VA / 1100 VA / 600 VA / 1500 VA / ◗ 360W 550 W 660 W 900 W Nominal input voltage 165V - 285V, adjustable to 150V - 285 or 175V - 285V ◗...
  • Seite 6: Operating Conditions

    CD-ROM 7 (or downloadable EATON to ensure correct operation Battery charge: The UPS charges from the eaton.com site) can be ◗ of the UPS. the battery as soon as it is configured to monitor the UPS The battery must be disposed ◗...
  • Seite 7: Troubleshooting

    Troubleshooting (For further information, visit the eaton.com site or contact after-sales support.) Problem Diagnostic Solution The battery backup outlets 9 Button 13 is not lighted on. Press button 13 and check that it ◗ ◗ ◗ are not supplied with power.
  • Seite 8: Conditions D'utilisation

    (risque d’électrocution) Les logiciels disponibles sur le CD- et par des éléments autorisés par Rom 7 (ou téléchargeables sur le EATON afin de garantir le bon site web www.eaton.com) peuvent Charge batterie : l'ASI charge sa ◗ fonctionnement de l'appareil.
  • Seite 9 Dépannage (Pour toute information, consulter le site www.eaton.com ou notre Service Après-Vente) Symptôme Diagnostic Remède Les prises secourues 9 ne Le bouton 13 n’est pas allumé. Appuyer sur le bouton 13 et ◗ ◗ ◗ sont pas alimentées. vérifier qu’il s'est allumé en vert.
  • Seite 10: Allgemeine Betriebsbedingungen

    Autonomiezeit, schaltet Ausgangssteckdosen 9 der USV anschließen (siehe Abb. B). Der die USV ab und startet bei Netzrückkehr Ellipse MAX 600 wieder automatisch. Nach vollständiger angegebene Nennstrom (in A) darf nicht überschritten werden. Entladung sind einige Stunden erforderlich, bis die volle Autonomiezeit ◗...
  • Seite 11: Fehlerbehebung

    Fehlerbehebung (Weitere Informationen unter www.eaton.com oder bei Ihrem EATON-Kundendienst) Fehler Fehlerursache Fehlerbehebung ◗ Keine Spannung an den ◗ Taster 13 leuchtet nicht. ◗ Taster 13 betätigen; grüne Kontroll-LED gepufferten Steckdosen 9 . muß leuchten. ◗ Keine Stromversorgung der ◗ Geräte sind nicht an die gesicherten ◗...
  • Seite 12: Condizioni Di Utilizzo

    (computer, poi si riavvia automaticamente schermo, modem) sulle prese con al momento del ritorno della Ellipse MAX 600 alimentazione di soccorso fornita corrente elettrica. Dopo una scarica dalla batteria 9 e protette contro completa, sono necessarie alcune le sovratensioni (vedi figura B), ore per ripristinare un’autonomia...
  • Seite 13: Interventi Di Riparazione

    Interventi di riparazione (Per ulteriori informazioni, consultare il sito www.eaton.com o rivolgersi al nostro Servizio Assistenza) Sintomo Diagnosi Rimedio Le prese assistite 9 non Il tasto 13 non è acceso. Premere il tasto 13 e verificare che ◗ ◗ ◗...
  • Seite 14: Condiciones De Uso

    (riesgo de electrocución) autorizado Serie) 6 suministrado. se conecta a la red eléctrica sin por EATON con el fin de garantizar El software disponible en el CD-Rom importar el estado del interruptor el correcto funcionamiento del 7 (disponible para descarga 13 .
  • Seite 15 Reparación (Para cualquier información, consultar el sitio www.eaton.com o nuestro servicio de posventa) Síntoma Diagnóstico Solución Las tomas auxiliadas 9 no El interruptor 13 no esta Accione el interruptor 13 y compruebe ◗ ◗ ◗ son alimentadas. encendido. que esté encendido en verde.
  • Seite 16: Gebruiksaanwijzing

    Als de stroomuitval langer duurt ◗ UPS met FR/DIN aansluitingen, of dan de batterijautonomie, schakelt met het netsnoer van uw computer Ellipse MAX 600 de UPS uit en start het systeem bij een UPS met IEC/UNIVERSEEL automatisch weer na terugkeer aansluitingen (zie figuur A).
  • Seite 17: Problemen Oplossen

    Problemen oplossen (ga voor informatie naar onze website www.eaton.com of bel met onze servicedienst) Probleem Oorzaak Oplossing De battery backup-aansluitingen De knop 13 brandt niet. Druk op de knop 13 en controleer ◗ ◗ ◗ 9 krijgen geen stroom. of hij groen verlicht is.
  • Seite 18: Condições De Utilização

    é de electrocussão) e por pessoas através do cordão específico USB ligada à rede eléctrica, qualquer autorizadas pela EATON de modo a ou série 6 fornecido. que seja o estado do botão 13 . Na garantir o correcto funcionamento Os softwares disponíveis no...
  • Seite 19 Resolução de problemas (para qualquer informação, consultar www.eaton.com o nosso serviço Pós-Venda). Sintoma Diagnóstico Solução As tomadas protegidas 9 não O botão 13 não estã aceso. Premer o botão 13 e verificar se ◗ ◗ ◗ são alimentadas. está devidamente aceso em verde.
  • Seite 20 MAU-00033 AE...
  • Seite 21 MAU-00033 AE...
  • Seite 22 MAU-00033 AE...
  • Seite 23 MAU-00033 AE...
  • Seite 24 MAU-00033 AE...
  • Seite 25 MAU-00033 AE...
  • Seite 26 MAU-00033 AE...
  • Seite 27 MAU-00033 AE...
  • Seite 28 MAU-00033 AE...
  • Seite 29 MAU-00033 AE...
  • Seite 30 MAU-00033 AE...
  • Seite 31 MAU-00033 AE...
  • Seite 32 Ellipse MAX 600 Ellipse MAX 850/1100 /1500 www.eaton.com EATON www.eaton.com MAU-00033 AE...
  • Seite 33 MAU-00033 AE...
  • Seite 34 EATON, www.eaton.com www.eaton.com MAU-00033 AE...
  • Seite 35 MAU-00033 AE...
  • Seite 36 EATON MAU-00033 AE...
  • Seite 37 MAU-00033 AE...
  • Seite 38 MAU-00033 AE...
  • Seite 39 Ellipse MAX 600 Ellipse MAX 850/1100 /1500 www.eaton.com EATON www.eaton.com MAU-00033 AE...
  • Seite 40 MAU-00033 AE...
