Astralpool BASIC Handbuch Seite 4

1) Input pH or Redox Probe
2) Input Temperature Probe (PT100)
3) Input Level Probe (Product Tank
4) Input Flow Rate (High Voltage 230 Vac)
5) Output Relay Alarm remote (Dry
contact, Relay 250 Vac 10 A)
6) Output Relay Drive Solenoid Valve (Dry
contact, Relay 250 Vac 10 A)
7) Power Supply 230 Vac
8) Switch Power Supply
Redox Probe Calibration
Keep probe into Buffer solution
465mv_Quality_100%
Quality Probe
7
Press Cal Key 3 Secondù
10
Code 0000137051
Wire Connection:
Calibration
Press Cal Key 3 Seconds
5
Normal Status
11
rev. 1.0
Wash
465mv___Press_CAL
Calibration During 1 minutes
Wait________60s
