Celestron InfiniView Bedienungsanleitung Seite 7

4. oBsErVing AnD CAPTUring iMAgEs: DigiTAL iMAging
a. Make sure your Infi niView™ is powered ON.
Put object onto the stage
B.
Place your specimen on the stage (5). If your object is thin
enough, secure it to the stage using the chrome clips.
d.
Rotate the Focus Wheel (3) to get a fi ne focus on the object.
F.
To record an image, press the Capture Button (8).
NOTE:
Press the Playback/Left button on the LCD screen housing to scroll between
Still Image Capture mode and Video Capture mode.
c.
Rotate the Stage Height adjustment Wheel (7) to bring
your specimen closer to the Microscope Tube (4).
E.
When the desired focus is achieved, lock the stage
in position by tightening the Stage lock Wheel (6)
g.
While in video mode, press the Capture Button to start
recording video. Press the button again to stop.
7
ENGLISH
