Display mode "ANZEIGEMODUS"

The display mode menu item shows the following information:
ANZEIGEMODUS
1. LINIE: WEISS
2. K.BILD: WEISS
3. H-GRUND: WEISS
4. V-NORM: CCIR
5. KONTRASTLEVEL
6. HELLIGKEITSLEVEL
7. AUFNAHME
Proceed as follows to change the display setting:
1. Use the arrow keys ▲ (5) and ▼ (6) to move the cursor to the item you want to change.
2. Use the -/+ keys (7) and (8) to change the value of the item.
LINE "LINIE"
The LINE item defines the grey value of the separator line in the quad display.
NO PICTURE "K.BILD"
The NO PICTURE item defines the grey value of the picture when a video signal fails.
BACKGROUND "H-GRUND"
The BACKGROUND item defines the grey value of the picture when a video signal fails.
VIDEO STANDARD "V-NORM"
The VIDEO STANDARD item defines the TV standard to be used for the B&W picture. For Europe
please use the CCIR setting.
CONTRAST LEVEL "KONTRASTLEVEL"
To change the setting of the contrast value for each camera individually, select the CONTRAST
LEVEL item and confirm with the – or + key (7) or (8). The display changes. You can then change
the contrast value with the -/+ keys (7) and (8).
To exit the menu, briefly press the Menu key (1).
BRIGHTNESS LEVEL "HELLIGKEITSLEVEL"
To change the brightness setting for each camera individually, select the BRIGHTNESS LEVEL item
and confirm with the – or + key (7) or (8). The display changes. You can then change the brightness
value with the -/+ keys (7) and (8).
To exit the menu, briefly press the Menu key (1).
RECORDING "AUFNAHME"
The RECORDING item defines the video signal to be output to the video recorder. The choices are:
- QUAD: a quad split is always output.
- LIVE: the currently displayed picture is output.
When you have finished the display mode entry, briefly press the
Linie (grey value of the separator line)
K. Bild (grey value of the video loss display)
H-Grund (grey value of background display)
V-Norm (video standard)
Kontrastlevel (contrast level)
Helligkeitslevel (brightness level)
Aufnahme (recording)
30
Menu key.
