Overview

• 4-channel duplex Quad
• Real-time display (50 fields/second)
• Integrated motion detector for each camera and selectable sensitivity
• An alarm input per camera and an alarm output for alarm recording
• 2 video outputs for live picture and recorder
• 80-event memory, German on-screen menu
• Various display modes (quad split, picture-in-picture, sequencing function, single picture)
• Zoom function (live and playback), digital picture memory for "freezing the picture"
• Image resolution: 1024 (H) x 768 (V) pixel and 256 grey levels
•
Compatible with B&W cameras (CCIR/EIA)
•
BNC connectors with loop-through outputs for each camera
•
Non-volatile memory to protect all settings in the event of power failure.
