GMC SYT210 Bedienungsanleitungen

www.gmctools.com
SYT210_Full Manual A2.indd 1
OPERATING & SAFETY INSTRUCTIONS
BEDIENINGS- EN VEILIGHEIDSINSTRUCTIES
INSTRUCTIONS D'UTILISATION ET CONSIGNES
DE SECURITE
BEDIENUNGS- & SICHERHEITSANWEISUNG
ISTRUZIONI PER L'USO E LA SICUREZZA
INSTRUCCIONES DE FUNCIONAMIENTO Y SEGURIDAD
1400W
210MM (8 ⁄ ") COMPACT SLIDE
1
4
COMPOUND MITRE SAW
WITH LASER LINE
SYT210
DE DIA BEWERKT ZAAG IN VERSTEK
EN DUBBELE LASERLIJNGENERATOR
GLISSEZ LA SCIE DE MITRE
AVEC SYSTÈME DE DOUBLE LIGNES DE GUIDAGE LASER
SCHIEBEN SIE GEHREN-SÄGE
MIT ZWEIFACH-LASER-LINIENGENERATOR
FACCIA SCORRERE LA SEGA DEL MITRA
CON DOPPIO GENERATORE LINEA LASER
RESBALE LA SIERRA DEL INGLETE
CON GENERADOR DE LÍNEAS DE LÁSER DOBLE
GB DO NOT USE BEFORE VIEWING AND d VERWENDEN SIE NICHT VOR
UNDERSTANDING THE FULL OPERATING BETRACHTUNG UND VERSTÄNDNIS DIE
INSTRUCTIONS VOLLEN BEDIENUNGSANLEITUNGEN
nL GEBRUIK NIET ALVORENS EN BEGRIJPEND I NON USI PRIMA DELL'OSSERVAZIONE
DE VOLLEDIGE WERKENDE INSTRUCTIES E DELLA COMPRENSIONE LE ISTRUZIONI DI
TE BEKIJKEN FUNZIONAMENTO COMPLETE
F N'EMPLOYEZ PAS AVANT LE VISION
E NO UTILICE ANTES DE LA VISIÓN Y DE
NEMENT ET L'ARRANGEMENT LES PLEINES LA COMPRENSIÓN LAS INSTRUCCIONES DE
CONSIGNES D'UTILISATION MANEJO COMPLETAS
WArnInG. Do not lift the saw whilst holding on to the guards. Use the operating
GB
handle (1).
trAnSPortAtIon
IntroductIon
Lift the mitre saw only when the saw arm is locked in the down position, the saw is
Thank you for purchasing this GMC Tool. These instructions contain information switched off and the plug is removed from the power point. Only lift the saw by the
necessary for safe and effective operation of this product. This product has unique operating handle (1) or outer castings (fig. C). Do not lift the saw using the guards.
features. Even if you are familiar with similar products, please read this manual
carefully to make sure you get the full benefit from them. Keep this manual close to
C
hand and ensure all users of this tool have read and fully understand them.
dEcLArAtIon oF conForMItY the undersigned: Mr Philip Ellis as
authorized by: GMC Declare that: Product codE: SYT210 dEScrIPtIon:
Compact Slide Compound Mitre Saw Electric power: 230-240V~ 50Hz 1400W
conForMS to tHE FoLLoWInG dIrEctIVES: • Directive 2004/108/EC
Electromagnetic Compatability • Directive 2006/95/EC Low Voltage Directive
• Directive 2006/42/EC Machinery Directive • Directive 2002/95/EC RoHS • EN61029-
1:2009, EN61029-2-9:2002, EN60825-1:1994+A1+A2 • EN 55014-1:2006, EN 55014- BEncH MountInG
2:1997+A1:2001 • EN 61000-3-2:2006, EN 61000-3-3:1995+A1:2001+A2:2005
The saw base has 5 holes in the base to facilitate bench mounting (fig. D). 1.Mount
tHE tEcHnIcAL docuMEntAtIon IS KEPt BY GMc date: 01/01/10
the saw to a level, horizontal bench or work table using bolts (not supplied) and fix
Signed by:Mr Philip Ellis,
the saw to the bench using 5 bolts. 2. If desired, you can mount the saw to a piece of
13mm or thicker plywood which can then be clamped to your work support or moved
to other job sites and re-clamped. cAutIon. Make sure that the mounting surface is
not warped as an uneven surface can cause binding and inaccurate sawing.
Managing director
D
SPEcIFIcAtIonS: Input power: 1400W no load speed: 5000min -1 Blade size:
Ø210mm x Ø30mm bore number of teeth: 24 Mitre table angles: 0° to 45° left &
right Bevel cuts: 0° to 45° left Straight cut at 0° x 0°: 200mm x 58mm Mitre cut at
45° x 0°: 140mm x 58mm Bevel cut at 0° x 45°: 200mm x 30mm compound mitre
cut at 45° x 45°: 140mm x 30mm Insulation class: Double insulated the sound
intensity level for the operator may exceed 85dB(A) and sound protection
measures are necessary
SAFEtY ruLES For LASEr LIGHtS
rELEASE KnoB The release knob (20) is provided for holding the cutting head
The laser light/laser radiation used in the GMC laser system is Class 2 with
down whilst transporting or storing the mitre saw (fig. E). The saw must never be
maximum 1mW and 650nm wavelengths. These lasers do not normally present an
used with the release knob locking the head down.
optical hazard, although staring at the beam may cause flash blindness. WARNING.
Do not stare directly at the laser beam. A hazard may exist if you deliberately SLIdE LocK When tightened, the slide lock (21) prevents the saw head from
stare into the beam, please observe all safety rules as follows; • The laser shall
sliding. Tighten the slide lock during transportation (fig. F).
be used and maintained in accordance with the manufacturer's instructions.
• Never aim the beam at any person or an object other than the workpiece. • The
MItrE tABLE LocKS The mitre table locks (7) are used to lock the table at the
laser beam shall not be deliberately aimed at personnel and shall be prevented
desired mitre angle (fig. G).The mitre saw cuts from 0° to 45° both left and right.
from being directed towards the eye of a person. • Always ensure the laser beam is To adjust the mitre angle loosen the mitre table locks and rotate the mitre table to
aimed at a sturdy workpiece without reflective surfaces. I.e. wood or rough coated the desired position. The mitre table features positive click stops for quick setting
surfaces are acceptable. Bright shiny reflective sheet steel or the like is not suitable
of common mitre angles.WArnInG. Be sure to tighten the mitre table locks before
for laser use as the reflective surface could direct the beam back at the operator.
making a cut. Failure to do so could result in the table moving during the cut and
• Do not change the laser light assembly with a different type. Repairs must be
cause serious personal injury.
carried out by the laser manufacturer or an authorised agent. CAUTION. Use of
controls or adjustments or performance of procedures other than those specified E F
herein may result in hazardous radiation exposure. Please refer to the relevant
European standards, EN60825-1 for more information on Lasers.
SAFEtY ruLES For MItrE SAWS
WArnInG. Before connecting a tool to a power source (mains switch power
point receptacle, outlet, etc.) be sure that the voltage supply is the same as that
specified on the nameplate of the tool. A power source with a voltage greater than
that specified for the tool can result in serious injury to the user, as well as damage
to the tool. If in doubt, do not plug in the tool. Using a power source with a voltage
BEVEL LocK The bevel lock (23) is used to set the blade at the desired bevel angle
less than the nameplate rating is harmful to the motor. Your tool is double insulated (fig. H). The mitre saw bevel cuts from 0° to 45° to the left. To adjust the bevel angle
for additional protection against a possible electrical insulation failure within the tool. loosen the bevel lock and adjust the saw arm to the desired bevel angle.WArnInG.
Always remove the plug from the mains socket before making any adjustments
Be sure to tighten the bevel lock before making a cut. Failure to do so could result in
or maintenance, including changing the blade. • When operating the saw, use
the saw arm moving during the cut and cause serious personal injury.
safety equipment including safety goggles or shield, ear protection, dust mask and
protective clothing including safety gloves. • Ensure that there is adequate general
SPIndLE LocK Button The spindle lock button (28) prevents the blade in the
or localised lighting. • Do not use the saw unless the guards are in place. • Do not saw from rotating (fig. I). Depress and hold the spindle lock button while installing,
use the saw to cut metal or masonry. • Do not let anyone under 18 years operate changing, or removing the blade.
this saw. • Ensure that the operator is adequately trained in the use, adjustment
and operation of the machine. • Do not use this saw to cut firewood. • Keep the
rotAtInG LoWEr BLAdE GuArd The rotating lower blade guard (4) provides
area free of tripping hazards. • Report faults in the machine, including guards and
protection from both sides of the blade. It retracts over the upper blade guard (3) as
saw blades, as soon as they are discovered. • Ensure that the machine is always the saw is lowered into the workpiece workpiece (fig. J).
fixed to a bench, whenever possible. • Always stand to one side when operating
the saw. • Never use a cracked or distorted saw blade. • When cutting round wood,
H I
use clamps that prevent the workpiece from turning on both sides of the blade.
• Never use your hands to remove sawdust, chips or waste close by the blade. • Use
only blades as recommended by the manufacturer and which conform to EN 847-1.
• Do not use blades of High Speed Steel (HSS blades). • If the table insert is
damaged or worn, have it replaced by an authorised service centre. • Rags, cloths,
cord and string and the like should never be left around the work area. • Avoid
cutting nails. Inspect the workpiece and remove all nails and other foreign objects
before beginning sawing. • Support the work properly. • Refrain from removing any
cut-offs or other parts of the workpiece from the cutting area whilst the machine duSt BAG The dust bag (26) fits over the dust extraction port (18) (fig. K). For more
is running and the saw head is not in the rest position. • Do not attempt to free a efficient operation, empty the dust bag when it is no more than half full. This allows
jammed blade before first switching off the machine. • Do not slow or stop a blade
better air flow through the bag.
with a piece of wood. Let the blade come to rest naturally. • If you are interrupted
when operating the saw, complete the process and switch off before looking up.
turnInG on And oFF 1. To turn the saw on depress and hold the on/off trigger
• Periodically check that all nuts, bolts and other fixings are properly tightened. • Do
switch (17) (fig. L). 2. To turn the saw off release the on/off trigger switch (17).
not store materials or equipment above a machine in such a way that they could
fall into it. • Always hold the saw on parts that are insulated. If you accidentally cut
turnInG on tHE LASEr LInE GEnErAtor The laser line generator emits an
into hidden wiring or the saw's own cable, the metal parts of the saw will become
intense narrow beam of pure red light to guide you as you cut. It improves operator
"live". Switch off at the mains and remove the plug immediately. • Never saw near
cutting vision, enables faster set-up, increases accuracy and improves safety. To turn
combustible liquids or gases. • Note the direction of rotation of the motor and the
on the laser line press the laser light on/off switch (16) (fig. M). To turn off the laser
blade. • Do not lock the movable guard in the open position and always ensure that it press the laser light on/off switch (16) one more time.
is working properly, freely rotating and returning to fully cover the teeth of the blade.
• Connect the saw to a dust collection devise and ensure that it is operated properly. As
K L
the operator of the saw, please make sure that you understand factors that influence
exposure to dust, including the type of material to be machined, the importance
of local extraction and the proper adjustment of hoods/baffles/shoots of your dust
extraction system. We recommend that you always wear a dust mask when operating
this saw. • Wear gloves when handling saw blades and rough materials. • Saw blades
shall be carried in a holder wherever possible. • Select saw blades in relation to the
material being cut. • Use correctly sharpened saw blades and observe the maximum
speed marked on the blade. • Take additional care when trenching (slotting).
• The mitre saw can be safely carried by the carrying handle but only once it has SEttInG tHE tABLE SquArE WItH tHE BLAdE
been removed from the mains power and secured in the locked down position. 1. Make sure that the electrical plug is removed from the power point. 2. Push the
• Ensure that the arm is properly secure when bevelling. • Keep the floor area around
saw arm (19) down to its lowest position and engage the release knob (20) to hold
the machine level, well maintained and free of loose materials. • Ensure that you are
the saw arm in the transport position (fig. N). 3. Loosen the mitre locks (7). 4. Rotate
trained in the use, adjustment and operation of the machine. • Do not remove any
the table (8) until the pointer is positioned at 0º. 5. Tighten the mitre locks (7). 6.
cut-offs from the cutting area until the guard is fully locked in place and the blade Loosen the bevel lock (23) and set the saw arm (19) at 0º bevel (the blade at 90º to
has come to rest. • When cutting long pieces which extend well over the table width, the mitre table). Tighten the bevel lock (23) (fig. O). 7. Place a set square against
ensure that the ends are adequately supported at the same height as the saw table
the table (8) and the flat part of the blade (fig. P). Note. Make sure that the square
top. Supports should be positioned in such a way to ensure that the workpiece does
contacts the flat part of the saw blade, not the teeth. 8. Rotate the blade by hand and
not fall to the ground once the cut has been made. A number of supports at regular
check the blade-to-table alignment at several points. 9. The edge of the set square
intervals may be required if the workpiece is extremely long. Wear goggles. Wear
and the saw blade should be parallel. 10. If the saw blade angles away from the set
earmuffs. Wear a breathing mask. square, adjust as follows. 11. Use an 8mm wrench or adjustable spanner to loosen
the lock nut securing the 0° bevel adjustment screw (25) (fig. Q). Also, loosen the
WArnInG. The tool must be used only for its prescribed purpose. Any use other
bevel lock (23). 12. Adjust the 0° bevel adjustment screw (25) with the hex key (fig.
than those mentioned in this manual will be considered a case of misuse. The user
R) to bring the saw blade into alignment with the square. 13. Loosen the Phillips
and not the manufacturer shall be liable for any damage or injury resulting from such
head screw holding the pointer of the bevel scale (12) and adjust the position of
cases of misuse. To use this tool properly, you must observe the safety regulations, the pointer so that it accurately indicates zero on the scale (fig. S). Retighten the
the assembly instructions and the operating instructions to be found in this manual. screw. 14. Retighten the bevel lock (23) and the lock nut securing the 0° bevel
All persons who use and service the machine have to be acquainted with this manual
adjustment screw (25).
and must be informed about its potential hazards. Children and frail people must
not use this tool. Children should be supervised at all times if they are in the area
N O
in which the tool is being used. It is also imperative that you observe the accident
prevention regulations in force in your area. The same applies for general rules of
occupational health and safety. The manufacturer shall not be liable for any changes
made to the tool nor for any damage resulting from such changes. Even when the
tool is used as prescribed it is not possible to eliminate all residual risk factors. The
following hazards may arise in connection with the tool's construction and design:
• Damage to hearing if effective hearing protection is not worn. • Always remove
the plug from the mains socket before making any adjustments or maintenance,
including changing the blades and adjusting the depth of cut.
Q R
unPAcKInG
Due to modern mass production techniques, it is unlikely that your GMC Power Tool
is faulty or that a part is missing. If you find anything wrong, do not operate the tool
until the parts have been replaced or the fault has been rectified. Failure to do so
could result in serious personal injury. 1. Remove all loose parts from the carton. 2.
Remove the packing materials from around the saw. 3. Using the operating handle
(1) carefully lift the saw from the carton and place it on a level work surface. 4. The
saw has been shipped with the saw arm locked in the down position. To release the
T
saw arm, push down on the top of the saw arm, pull on the release knob (20) (fig. A),
rotate it 45° and let go (fig. B), slowly raise the saw arm.
A B
45º
notE. The above procedure can also be used to check the angle of the saw blade to
the table at 45º bevel angle. The 45° bevel adjustment screw (24) is on the opposite
side of the saw arm (fig. T).
SEttInG tHE FEncE SquArE WItH tHE tABLE BEVEL cut
1. Make sure that the electrical plug is removed from the power point. 2. Push the A bevel cut is made by cutting across the grain of the workpiece with the blade
saw arm (19) down to its lowest position and engage the release knob (20) to hold angled to the fence and mitre table. The mitre table is set at the zero degree position
the saw arm in the transport position. 3. Loosen the mitre locks (7). 4. Rotate the and the blade set at an angle between 0º and 45º (fig. n). Use the slide action when
table (8) until the pointer is positioned at 0º. 5. Tighten the mitre locks (7). 6. Using cutting wide workpieces. 1. Pull on the release knob (20) and lift the saw arm to its
the 6mm hex key provided, loosen the two screws securing the fence (11) to the base full height. 2. Loosen the mitre locks (7). 3. Rotate the mitre table (8) until the pointer
(fig. U). 7. Place a square against the fence (11) and alongside the blade (fig. V). 8. aligns with zero on the mitre scale (10). 4. Retighten the mitre locks (7). WArnInG.
Adjust the fence (11) until it is square with the blade. 9. Tighten the screws securing Be sure to tighten the mitre locks before making a cut. Failure to do so could result in
the fence (11). 10. Loosen the Phillips head screw holding the pointer of the mitre the table moving during the cut, causing serious personal injury. 5. Loosen the bevel
scale (10) and adjust it so that it accurately indicates the zero position on the mitre lock (23) and move the saw arm (19) to the left to the desired bevel angle (between
scale (fig. W). 11. Retighten the screw securing the mitre scale pointer. 0º and 45º). Tighten the bevel lock (23). 6. Place the workpiece flat on the table with
one edge securely against the fence (11). If the board is warped, place the convex
side against the fence. If the concave side is placed against the fence, the board
U V W
could break and jam the blade. 7. When cutting long pieces of timber, support the
opposite end of the timber with a roller stand or a work surface that is level with the
saw table. 8. Before turning on the saw, perform a dry run of the cutting operation
to check that there are no problems. 9. Hold the operating handle (1) firmly and
squeeze the switch trigger (17). Allow the blade to reach maximum speed. 10. Press
the release latch (2) and slowly lower the blade into and through the workpiece.
11. Release the switch trigger (17) and allow the saw blade to stop rotating before
raising the blade out of the workpiece. Wait until the blade stops before removing
cHAnGInG A BLAdE the workpiece.
dAnGEr! Never try to use a blade larger than the stated capacity of the saw. It
might come into contact with the blade guards. Never use a blade that is too thick to
n
allow the outer blade washer to engage with the flats on the spindle. It will prevent
the blade screw from properly securing the blade on the spindle. Do not use the
saw to cut metal or masonry. Ensure that any spacers and spindle rings that may be
required suit the spindle and the blade fitted. 1. Make sure that the electrical plug
is removed from the power point. 2. Push down on the operating handle (1) and pull
the release knob (20) to disengage the saw arm (19) (fig. X). 3. Raise the saw arm
(19) to its highest position. 4. Using a Phillips head screwdriver loosen and remove
the Phillips head screw that secures the guard retraction arm to the rotating blade
guard (fig. Y). 5. Using a Phillips head screwdriver loosen and remove the Phillips coMPound MItrE cut
head screw that secures the blade bolt cover (fig. Z). A compound mitre cut involves using a mitre angle and a bevel angle at the same
time (fig. o). It is used in making picture frames, to cut mouldings, making boxes
X Y Z with sloping sides and for roof framing. Always make a test cut on a piece of scrap
wood before cutting into the good material. Use the slide action when cutting wide
workpieces. 1. Pull on the release knob (20) and lift the saw arm to its full height. 2.
Loosen the mitre locks (7). 3. Rotate the mitre table (8) until the pointer aligns with
the desired angle on the mitre scale (10). 4. Retighten the mitre locks (7). WArnInG.
Be sure to tighten the mitre locks before making a cut. Failure to do so could result in
the table moving during the cut, causing serious personal injury. 5. Loosen the bevel
lock (23) and move the saw arm (19) to the left to the desired bevel angle (between
0º and 45º). Tighten the bevel lock (23). 6. Place the workpiece flat on the table with
6. Pull the rotating blade guard (4) down then swing it up together with the blade one edge securely against the fence (11). If the board is warped, place the convex
bolt cover (15). When the rotating blade guard (4) is positioned over the upper fixed side against the fence. If the concave side is placed against the fence, the board
blade guard (3) it is possible to access the blade bolt (fig. a). 7. Hold the rotating could break and jam the blade. 7. When cutting long pieces of timber, support the
guard (4) up and press the spindle lock button (28) (fig. b). Rotate the blade until opposite end of the timber with a roller stand. 8. Before turning on the saw, perform
the spindle locks. a dry run of the cutting operation to check that there are no problems. 9. Hold the
G operating handle (1) firmly and squeeze the switch trigger (17). Allow the blade to
reach maximum speed. 10. Press the release latch (2) and slowly lower the blade
a b
into and through the workpiece. 11. Release the switch trigger (17) and allow the
saw blade to stop rotating before raising the blade out of the workpiece. Wait until
the blade stops before removing the workpiece.
o
8. Use the 6mm hex key provided to loosen and remove the blade bolt. (Loosen in a
clockwise direction as the blade screw has a left hand thread) (fig. c). 9. Remove the
flat washer, outer blade washer and the blade. 10. Wipe a drop of oil onto the inner
blade washer and the outer blade washer where they contact the blade. 11. Fit the
new blade onto the spindle taking care that the inner blade washer sits behind the
blade (fig. d). cAutIon. To ensure correct blade rotation, always install the blade
with the blade teeth and the arrow printed on the side of the blade pointing down. The
direction of blade rotation is also stamped with an arrow on the upper blade guard.
12. Replace the outer blade washer (fig. e). 13. Depress the spindle lock button
(28) and replace the the flat washer and blade bolt. 14. Use the hex key to tighten
the blade bolt securely (tighten in an anti-clockwise direction). 15. Lower the blade
guard, hold the rotating lower blade guard (4) and blade bolt cover (15) in position
and tighten the fixing screw (fig. f). 16. Replace the guard retraction arm and secure
J onto the rotating blade guard. 17. Check that the blade guard operates correctly and
covers the blade as the saw arm is lowered. 18. Connect the saw to the power supply
and run the blade to make certain that it is operating correctly.
c d e
f
M croSS-cuttInG (WItHout SLIdE ActIon)
When cutting a narrow piece of wood it is not necessary to use the slide mechanism.
In these cases ensure that the saw head is pushed back and the slide lock (21) is
screwed down to prevent the saw arm from sliding (fig. g). A crosscut is made by
cutting across the grain of the workpiece. A 90º crosscut is made with the mitre
table set at 0º. Mitre crosscuts are made with the table set at some angle other than
zero. 1. Pull on the release knob (20) and lift the saw arm (19) to its full height. 2.
Loosen the mitre locks (7). 3. Rotate the mitre table (8) until the pointer aligns with
the desired angle. 4. Retighten the mitre locks (7). WArnInG. Be sure to tighten
the mitre locks before making a cut. Failure to do so could result in the table moving
during the cut and cause serious personal injury. 5. Place the workpiece flat on the
table with one edge securely against the fence (11). If the board is warped, place
the convex side against the fence (11). If the concave side is placed against the
fence, the board could break and jam the blade. 6. When cutting long pieces of
timber, support the opposite end of the timber with a roller stand or a work surface
that is level with the saw table. 7. Before turning on the saw, perform a dry run of the
cutting operation to check that there are no problems. 8. Hold the operating handle
(1) firmly and squeeze the switch trigger (17). Allow the blade to reach maximum
speed. 9. Press the release latch (2) (fig. h) and slowly lower the blade into and
through the workpiece. 10. Release the switch trigger (17) and allow the saw blade to
stop rotating before raising the blade out of the workpiece. Wait until the blade stops
before removing the workpiece.
g h
P
o croSS-cuttInG (WItH SLIdE ActIon)
90
When cutting wide workpieces, first unscrew the slide lock (21) (fig. i). 1. Pull on the
release knob (20), raise the saw arm (19) to its highest position and slide it towards
you (fig. j). 2. Hold the handle firmly and squeeze the switch trigger (17). Allow the
blade to reach maximum speed. 3. Press the release latch (2) (fig. k) and slowly
lower the blade into the workpiece (fig. l) and slide it away from you at the same time
S until the workpiece is cut (fig. m). 4. Release the switch trigger (17) and allow the
saw blade to stop rotating before raising the blade out of the workpiece. Wait until the
blade stops before removing the workpiece.
i j k
l m
16/12/09 16:37:31
