Specifications

Model
Measurement method
Display
Blood pressure measurement range
Pulse measurement range
Calibration accuracy
Inflation/Deflation
Sets of memory
Cuff size
Operating temperature
Storage temperature
Unit weight
Power source
Auto power off
Service life
Wireless communication
Important
Read the operating instructions.
If the device is not used within the specified temperature, humidity and atmospheric pressure ranges,
the technical accuracy of the measurement cannot be guaranteed.
Classification:
Internally powered equipment
Type BF applied parts
Protected against solid foreign objects of 12.5 mm diameter and larger. Protected against water drops falling
vertically when the device is tilted up to 15°.
Not suitable for use in the presence of flammable anaesthetic mixtures with air, oxygen or nitrous oxide.
Continuous operation with short-time loading.
+40°C
Operating temperature
+10°C
10
BPW4500
Oscillometric
OLED display
40 ~ 255mmHg
40 ~ 199 beats/minute
Blood pressure: +/- 3 mmHg
Pulse rate: +/- 4% of reading
Automatic
Up to 100 readings
Fits wrist circumference: 12.5 - 21 cm (4.9 - 8.3 inch) min/max
+10 °C ~ + 40 °C, less than 85 % R.H. non-condensing
-20 °C ~ +55 °C, less than 85 % R.H. non-condensing
Approximately 125g (exluding batteries)
Alkaline battery: 2 x AAA (LR3) 1.5V
Approx. 60 seconds
5 years
Bluetooth® Smart
Frequency Range: 2.4GHz ISM Band (2400 - 2483.5 MHz)
Modulation: GFSK
Effective radiated power: <20dBm
+55°C
Storage temperature
-20°C
Storage humidity
