Compaction increases the density of the material and therefore increases
its load bearing capacity. Reduces air voids and therefore reduces the risk
of subsidence, expansion and contraction, due to ingress of water.
Safe Disposal Instructions for the protection of the environment.
The machine contains recyclable materials. Take the discarded apparatus
and accessories to the relevant recycling facilities.
Component
Operator handle
Main frame
Base plate
Eccentric weight
Petrol engine housing
Petrol engine covers
Various parts

TROUBLESHOOTING

Problem
Engine will not start.
Engine still will not
start.
Unit will not vibrate.
Paving blocks
damaged.
Bituminous surface
flaking (laminating).
Low travel speed.
It is recommended that an approved Evolution dealer carries out all major
maintenance and repairs. Always use genuine Evolution replacement
parts.
Before any maintenance is carried out on the machine, switch off the
engine and disconnect the HT lead from the sparkplug.
Always set the 'HULK' on level ground to ensure any fluid levels will be
correctly read. Only use recommended oils.
Running In Period
When the 'HULK' is first used from new, the engine oil must be changed
after the initial running in period as specified in the Routine Maintenance
chart on the following page.
ENVIRONMENT
Cause
No fuel.
Engine switched off.
Spark plug fouled.
Engine cold.
Engine flooded.
Major Fault.
Belt tension incorrect.
Air filter blocked.
Eccentric unit
damaged.
Plate in direct contact
with material.
Over compaction.
Layer thickness too
deep, (plate sinking).
Moisture content too
high or too low.

MAINTENANCE

Material
Steel
Steel
Steel
Steel
Aluminium
Synthetic material
Steel, Aluminium & Plastic
Remedy
Open fuel tap.
Fill fuel tank.
Switch engine on.
Clean and reset plug
gap.
Close choke.
Open choke, fully
open throttle, pull
recoil starter until
engine fires.
Contact Agent or
Evolution Power
Tools.
Adjust belt tension
Clean or renew air
filter.
Replace eccentric
unit.
Use a paving pad.
Remove and relay.
Remove some of the
material.
Remove material and
adjust.
